Шэньчжэнь Профессиональная печатная плата Fr4 94v0 OEM Заводская индивидуальная сборка печатных плат
- Категории: Rigid PCB >>>
- Поставщик: Finest,PCB,Assembly,Limited
Поделиться:
Описание и отзывы
Характеристики
Product Parameters
Specifications of the 37V (10S) lithium battery pack BMS
10S10A-170(10S)
Serial number Test item standard
1 Voltage Charging voltage DC: 42V CC/CV
Single section equalization voltage 4.20±0.025V
2 current Single section equilibrium current 42±5mA
Consumption current (self consumption) - Single node ≤20μA
Maximum continuous charging current 15A
Maximum continuous discharge current 15A
Overcharge protection (single section) Overcharge detection voltage 4.25±0.025V
The delay time of overcharge detection is 0.5S -- 1.5S
Overcharge recovery voltage 4.05±0.05V
4 Over discharge protection (single section) Over discharge detection voltage 2.80±0.062V
The delay time of overdischarge detection is 10mS - 150mS
The overdischarge recovery voltage is 3.00±0.062V
5 Overcurrent protection The overcurrent detection voltage is 0.62V
Overcurrent detection current 60±10A
Overcurrent detection delay time 5ms - 15ms
Recovery Status The load is disconnected and the system automatically recovers
6 Short-circuit protection Detects the external short-circuit
Detection delay time 200-500us
Recovery Status The load is disconnected and the system automatically recovers
7 Internal resistance protection cable (MOSFET) ≤20mΩ
8 Temperature The operating temperature ranges from -40 ℃ to +85℃
Storage temperature range -40 ~ +125℃
10S10A-170(10S)
Serial number Test item standard
1 Voltage Charging voltage DC: 42V CC/CV
Single section equalization voltage 4.20±0.025V
2 current Single section equilibrium current 42±5mA
Consumption current (self consumption) - Single node ≤20μA
Maximum continuous charging current 15A
Maximum continuous discharge current 15A
Overcharge protection (single section) Overcharge detection voltage 4.25±0.025V
The delay time of overcharge detection is 0.5S -- 1.5S
Overcharge recovery voltage 4.05±0.05V
4 Over discharge protection (single section) Over discharge detection voltage 2.80±0.062V
The delay time of overdischarge detection is 10mS - 150mS
The overdischarge recovery voltage is 3.00±0.062V
5 Overcurrent protection The overcurrent detection voltage is 0.62V
Overcurrent detection current 60±10A
Overcurrent detection delay time 5ms - 15ms
Recovery Status The load is disconnected and the system automatically recovers
6 Short-circuit protection Detects the external short-circuit
Detection delay time 200-500us
Recovery Status The load is disconnected and the system automatically recovers
7 Internal resistance protection cable (MOSFET) ≤20mΩ
8 Temperature The operating temperature ranges from -40 ℃ to +85℃
Storage temperature range -40 ~ +125℃
Layers | Mass production: 2~58 layers / Pilot run: 64 layers |
Max. Thickness | Mass production: 394mil (10mm) / Pilot run: 17.5mm |
Material | FR-4 (Standard FR4, Mid-Tg FR4,Hi-Tg FR4, Lead free assembly material) , Halogen-Free, Ceramic filled , Teflon, Polyimide, BT,PPO, PPE, Hybrid, Partial hybrid, etc. |
Min. Width/Spacing | Inner layer: 3mil/3mil (HOZ), Outer layer: 4mil/4mil(1OZ) |
Max. Copper Thickness | UL certificated: 6.0 OZ / Pilot run: 12OZ |
Min. Hole Size | Mechanical drill: 8mil(0.2mm) Laser drill: 3mil(0.075mm) |
Max. Panel Size | Custom |
Aspect Ratio | 18:1 |
Surface Finish | HASL,Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger |
Special Process | Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Partial high density, Back drilling, and Resistance control |
Why Choose Us
Delivery Time | Normal Delivery Time: | 24 hours ( fastest 12 hours quick-turn) | ||||
Small Production: | 72 hours( fastest 24 hours quick-turn) | |||||
Medium Production: | 5 working days | |||||
Capacity | SMT assembly | 500W point/day | ||||
THT assembly | 30W point/day | |||||
Components | A full set of substitute materials | Have a mature component procurement management system, and provide cost-effective services for OEM projects. | ||||
Only SMT | Do SMT and backhand welding according to components and PCB boards provided by customers. | |||||
Components purchasing | Customers provide core components, and we provide substituting services for other components | |||||
FAQ
1, ARE YOU A FACTORY OR TRADE COMPANY?
-FINEST is a PCB manufacturer with three factories.
2, WHAT PAYMENT TERMS DO YOU ACCEPT?
-T/T, West Union, D/A, samples accept Paypal.
3, WHAT DELIVERY TERMS COULD YOU DO?
-FOB Shenzhen, FOB HK, CFR, CIF, DDU.
4, DO YOU HAVE MOQ?
-No. But for orders less than 3s.q.m. set up cost will be charged.
5, WHAT IS YOUR STANDARD LEAD TIME?
-Samples: 3~5 days (1L~4L), 5~8 working days >6L
Middle volume production (less than 200 s.q.m): 7~8 working days for 1L and 2L, 8~15 working days for multilayer
Big volume production:15~20 working days.
Middle volume production (less than 200 s.q.m): 7~8 working days for 1L and 2L, 8~15 working days for multilayer
Big volume production:15~20 working days.
