Полифениленовые незаполненные полимерные пластиковые гранулы Sabic Noryl PPO PX1005X для помещений и
- Категории: PPO >>>
- Поставщик: Shenzhen,Samtion,Chemical,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
Sabic NoryL PX1005X
Sabic NoryL PX1005X resin is PPE+PS blend. Unfilled. Non-brominated, non-chlorinated FR system. UL94 V0/5VA rated. UL746C F1.
Excelent dielectric strength. Suitable for E/E market in indoor/outdoor applications.
Excelent dielectric strength. Suitable for E/E market in indoor/outdoor applications.
.
"NORYL" for the queen Mary innovation development by oxidation of xylene resin, plastic company in PPO for basic, one of aromatic polyether, the excellent material, through 17 kinds of feature combination, more conducive to injection molding, blow molding,extrusion, vacuum forming, to meet the industry needs lightweight, high security and more durable product requirements. Because of its excellent fire resistance, heat resistance, mechanical strength, electrical characteristics and dimensional stability, coupled with low water absorption and easy processing, it is widely used in water treatment equipment, computers, transaction machines,electronic parts, household appliances, communication equipment, water transportation parts and automobiles and other industries.
Product Paramenters
MECHANICAL | Value | Unit | Standard |
Tensile Stress, brk, Type I, 5 mm/min | 116 | MPa | ASTM D 638 |
Tensile Strain, brk, Type I, 5 mm/min | 2 | % | ASTM D 638 |
Tensile Modulus, 5 mm/min | 9150 | MPa | ASTM D 638 |
Flexural Stress, yld, 1.3 mm/min, 50 mm span | 180 | MPa | ASTM D 790 |
Flexural Stress, yld, 2.6 mm/min, 100 mm span | 162 | MPa | ASTM D 790 |
Flexural Modulus, 1.3 mm/min, 50 mm span | 8000 | MPa | ASTM D 790 |
Flexural Modulus, 2.6 mm/min, 100 mm span | 7170 | MPa | ASTM D 790 |
Hardness, Rockwell L | 108 | - | ASTM D 785 |
Tensile Stress, break | 117 | MPa | ISO 527 |
Tensile Strain, break | 1.8 | % | ISO 527 |
Tensile Modulus, 1 mm/min | 8740 | MPa | ISO 527 |
Flexural Stress | 183 | MPa | ISO 178 |
Flexural Modulus | 8710 | MPa | ISO 178 |
IMPACT | Value | Unit | Standard |
Izod Impact, unnotched, 23°C | 588 | J/m | ASTM D 4812 |
Izod Impact, notched, 23°C | 117 | J/m | ASTM D 256 |
Izod Impact, notched, -30°C | 124 | J/m | ASTM D 256 |
Izod Impact, unnotched 80*10*4 +23°C | 31 | kJ/m² | ISO 180/1U |
Izod Impact, unnotched 80*10*4 -30°C | 35 | kJ/m² | ISO 180/1U |
Izod Impact, notched 80*10*4 +23°C | 12 | kJ/m² | ISO 180/1A |
Izod Impact, notched 80*10*4 -30°C | 11 | kJ/m² | ISO 180/1A |
Charpy Impact, notched, 23°C | 12 | kJ/m² | ISO 179/2C |
Charpy Impact, notched, -30°C | 11 | kJ/m² | ISO 179/2C |
Charpy 23°C, Unnotch Edgew 80*10*4 sp=62mm | 39 | kJ/m² | ISO 179/1eU |
Charpy -30°C, Unnotch Edgew 80*10*4 sp=62mm | 47 | kJ/m² | ISO 179/1eU |
THERMAL | Value | Unit | Standard |
HDT, 0.45 MPa, 3.2 mm, unannealed | 142 | °C | ASTM D 648 |
HDT, 1.82 MPa, 3.2mm, unannealed | 137 | °C | ASTM D 648 |
HDT, 0.45 MPa, 6.4 mm, unannealed | 158 | °C | ASTM D 648 |
HDT, 1.82 MPa, 6.4 mm, unannealed | 137 | °C | ASTM D 648 |
CTE, -40°C to 40°C, flow | 3.06E-05 | 1/°C | ASTM E 831 |
CTE, -40°C to 40°C, xflow | 6.18E-05 | 1/°C | ASTM E 831 |
Vicat Softening Temp, Rate B/50 | 143 | °C | ISO 306 |
Vicat Softening Temp, Rate B/120 | 147 | °C | ISO 306 |
HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm | 143 | °C | ISO 75/Bf |
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 137 | °C | ISO 75/Af |
Relative Temp Index, Elec | 90 | °C | UL 746B |
Relative Temp Index, Mech w/impact | 90 | °C | UL 746B |
Relative Temp Index, Mech w/o impact | 90 | °C | UL 746B |
PHYSICAL | Value | Unit | Standard |
Specific Gravity | 1.29 | - | ASTM D 792 |
Water Absorption, 24 hours | 0.06 | % | ASTM D 570 |
Mold Shrinkage, flow, 3.2 mm | 0.1 - 0.4 | % | SABIC Method |
Melt Flow Rate, 300°C/5.0 kgf | 8.6 | g/10 min | ASTM D 1238 |
Melt Volume Rate, MVR at 300°C/5.0 kg | 7 | cm³/10 min | ISO 1133 |
ELECTRICAL | Value | Unit | Standard |
Dielectric Strength, in oil, 3.2 mm | 21.6 | kV/mm | ASTM D 149 |
Relative Permittivity, 50/60 Hz | 2.93 | - | ASTM D 150 |
Dissipation Factor, 50/60 Hz | 0.0009 | - | ASTM D 150 |
Arc Resistance, Tungsten {PLC} | 7 | PLC Code | ASTM D 495 |
Hot Wire Ignition {PLC) | 4 | PLC Code | UL 746A |
High Voltage Arc Track Rate {PLC} | 3 | PLC Code | UL 746A |
High Ampere Arc Ign, surface {PLC} | 4 | PLC Code | UL 746A |
Comparative Tracking Index (UL) {PLC} | 4 | PLC Code | UL 746A |
FLAME CHARACTERISTICS | Value | Unit | Standard |
UL Recognized, 94HB Flame Class Rating (3) | 1.47 | mm | UL 94 |
CSA (See File for complete listing) | LS88480 | File No. | CSA LISTED |
Oxygen Index (LOI) | 26 | % | ASTM D 2863 |
Company Profile
The Shenzhen Samtion Chemical Co., Ltd
Focus on the export and production support of engineering plastics and special modified materials
15 Years Experience
We are a leading supplier of top end engineering plastics raw materials.
The company is formed by a group of senior teams engaged in the sales and production of engineering plastic materials for over 15 years.
The company is formed by a group of senior teams engaged in the sales and production of engineering plastic materials for over 15 years.
More Than 1,000 Customers
Up to now, we have provided
high-quality products and services to more than 1,000 customers in various industries, including: electronics and electrical appliances, medical, food, automotive electronics, optoelectronic communications, photovoltaic new energy, water treatment,transportation and other industries.
high-quality products and services to more than 1,000 customers in various industries, including: electronics and electrical appliances, medical, food, automotive electronics, optoelectronic communications, photovoltaic new energy, water treatment,transportation and other industries.
Quality Assurance
Every batch of our products is subject to strict quality inspection to ensure the original supply. All products have MSDS, ROHS, SGS, REACH,
EU, UL, COC / COA certificates!!
EU, UL, COC / COA certificates!!
Why Choose Us
Our Warehouse
With a strong sales network and strength, we have warehousing services in Guangzhou, Dongguan, Shenzhen free trade zone, Hong Kong and other four places (conventional product inventory exceeds 1000 tons). We can provide customers with rapid response, professional service and excellent products!
Quality Control
Our authentic products are guaranteed, with complete qualifications and superior supply capacity and price advantages.
Our Team
Prompt：Fast response to customer needs, timely feedback process service.
Reliable： Customers give us trust and support, we feedback to customers guarantee and responsibility .
Innovative：Keep innovative thinking, synchronize with customers, and work together to explore new technologies and new products.
Win-Win： Cooperate for a bright future!
Reliable： Customers give us trust and support, we feedback to customers guarantee and responsibility .
Innovative：Keep innovative thinking, synchronize with customers, and work together to explore new technologies and new products.
Win-Win： Cooperate for a bright future!
FAQ
1.About samples
We can provide small batch procurement services; for new customers, we promise that the relevant sample fees will be refunded in bulk orders (up to a certain purchase amount).
2. About delivery time
We promise that if it is in stock, we will ship it within 2-5 days after confirming the payment; if it is a large quantity or
customized product, we will give a delivery time plan.
customized product, we will give a delivery time plan.
3. About the order process
（1）Demand confirmation
（2）Quotation
（3）Business conditions
（4）Testing sample
（5）PO/PI
（6）bulk order
（7）Transportation booking
（8）Final payment/Deliver
（9）Further
（2）Quotation
（3）Business conditions
（4）Testing sample
（5）PO/PI
（6）bulk order
（7）Transportation booking
（8）Final payment/Deliver
（9）Further
4. About quality assurance
We provide all product test authoritative reports required by customers, and all products have original factory shipment
certificates and qualifications. We will take full responsibility for any customer complaints caused by our product quality
problems.
certificates and qualifications. We will take full responsibility for any customer complaints caused by our product quality
problems.
5. About the shipping method
We can use land transportation, sea transportation, and air transportation according to customer requirements; we can also choose logistics suppliers according to customer requirements.
6. About the payment method
T/T, Western Union, PayPal, LC, etc. are all acceptable.
7. About MOQ:
The minimum quantity of an order is dependent on different types of materials, please ask our sales representatives
8. About quotation:
You can contact oursales representatives for a quotation at any time, we promise to reply within 7-24 hours
9. About technical support
We have a large technical support team, which can provide technical support including material selection, color matching service,mold consultation, product production service, etc. according to the situation of the customer's project.
10. Can the product be customized according to our requirements?
We can cooperate with customers in the selection of product materials in the early stage. If the required quantity meets the customization requirements, we can cooperate with product improvement or customization.
11. Are you factory or trade agent
We are a trader agent who has been engaged in the sales of engineering plastics in China for a long time; we have long-term represented and sold first-line professional engineering plastics brands including sabic.
12. What other products do you have?
You can find us for any needs about engineering plastics, including raw materials, production and processing services, mold design, etc. Our professional team is happy to serve you.
13. Why choose us?
We have the advantage of spot supply, our price advantage, we have more than 15 years of industry service experience, the most important thing is that we are dedicated to creating value for customers.
