Высокое качество мощный автоматический двигатель переменного тока 500 кг устройство
- Категории: Gate Operators >>>
- Поставщик: Chisung,Intelligence,Technology(shenzhen),Co.,Limited
Поделиться:
Описание и отзывы
Характеристики
Specification
Type | CSSGO-06-AC-400 |
Power supply | AC220V±10V 50HZ,AC110V±10V, 60Hz |
Current | 1.5A |
Absorbeb power of motor | 320w |
Max leaf length | 3m |
Max gate weight | 500kg |
Motor speed | 1.6cm/s |
Rotational speed | 1450RPM/min |
Thrust | 3000N |
Rod's max travel | 400mm |
Auto closing delay time | programmable (from 0 to 99 seconds) |
Gate move speed | 12S/90degrees |
Operating Temperature | -20°C~+70°C |
Relative Humidity | ≤95%, No Condensation |
Protection class | IP 45 |
Door opening angle | 90°,100°,110°,120° |
Product Description
Recommend Products
Packing & Delivery
carton
Company Profile
Certifications
Our Service
FAQ
1.What is material this product made of?
--------It is die-cast aluminum housing ,gear is copper ,stainless telescopic rod ,the motor wires is copper.
2.Can it be used outside?
-------- Yes, our dual swing gate opener could be used inside and outside of gate.
3.What is the frequncy of your remote control?
-------- It is 433Hz.
4.What is the longest time for opening and closing the gates?
-------- It is about 12s. It could be set up depending on your demand.
5.What's you warranty?
-------- 1 year time warranty, little charge after one year, and all the life time technology freely.
--------It is die-cast aluminum housing ,gear is copper ,stainless telescopic rod ,the motor wires is copper.
2.Can it be used outside?
-------- Yes, our dual swing gate opener could be used inside and outside of gate.
3.What is the frequncy of your remote control?
-------- It is 433Hz.
4.What is the longest time for opening and closing the gates?
-------- It is about 12s. It could be set up depending on your demand.
5.What's you warranty?
-------- 1 year time warranty, little charge after one year, and all the life time technology freely.
