Cat 246d skid steer loader
Product Description
Performance Characteristics:
1. Strong power and high energy-conservation and efficiency
* The renowned brand engine equipped features strong power, ultra-low emission, and higher fuel efficiency.
* The double speed motor with maximum speed up to 18km/h is installed to achieve high working efficiency. It can complete the site transfer rapidly and efficiently.
* It can respond faster to the needs of emergency working conditions such as rapid snow removing.
* The hydrostatic drive device is applied to realize quick change of appropriate attachments in the operation site.
2. Platform design for high reliability and firmness
* The serialization design is applied for the frame based on the skid- steer tonnage to realize high structural reliability. All critical structural parts are optimized by finite element analysis to realize reasonable stress distribution.
* The imported high-quality hydraulic parts are applied to realize higher reliability.
3. Multiple Applications
Inclined sweeper/ Snow plough/ Rotary tiller/ Closed sweeper/ Planer/ Manhole cover planer/ Breaking hammer/ Twist drill/ Continuous ditcher
Parameter
Description | Unit | Parameter value |
Rated load | kg | 1080 |
Tipping load | kg | 2160 |
Operating weight | kg | 3450 |
Maximum breakout force | kN | 22 |
Maximum operating height | mm | 4180 |
Bucket hinge pin height | mm | 3205 |
Cabin top height | mm | 1960 |
Length without bucket | mm | 2660 |
Length with bucket | mm | 3610 |
