Легкий для обслуживания бульдозер среднего размера DH24-C3 с
- Категории: Bulldozers >>>
- Поставщик: Liebty,Machinery,Technology,(Hangzhou),Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Contact
Sales Manager: Lily Li
Whatsapp/Mobile phone/WeChat:: +86 19956682258
Email:lily.liebty@gmail.com
Company: liebty Machinery(Hangzhou) Co.,Ltd
Add: Room 208, Building 3, Bo.1866, Binxing Road, Changhe Street, Zhejiang, China
Specifications
Parameter name | DH24-C3 XL (Extended version) | DH24-C3 LGP (Super-wetland version) |
Performance parameters | ||
Operating weight (Kg) | 23820 | 26420 |
Ground pressure (kPa) | 68.3 | 40.9 |
Engine | ||
Engine model | WP12 | WP12 |
Rated power/rated speed (kW/rpm) | 173/1900,195/1900, 213/1900 | |
Overall dimensions | 173/1900,195/1900, 213/1900 | |
Overall dimensions of machine (mm) | 6097*4365*3402 | |
Driving performance | 5940*3640*3335 | |
Forward speed (km/h) | 0~11 | 0~11 |
Reversing speed (km/h) | 0~11 | 0~11 |
Chassis System | ||
Center distance of track (mm) | 2000 | 2250 |
Width of track shoes (mm) | 560/610/660 | 910 |
Ground length（mm） | 3050 | 3482 |
Tank capacity | ||
Fuel tank (L) | 450 | 450 |
Working device | ||
Blade type | Semi-U blade | Semi-U blade |
Digging depth (mm) | 540 | 550 |
Ripper type | Tripe-teeth ripper | —— |
Ripping depth (mm) | 655 | —— |
Details Images
SHANTUI HOT SALE DH24-C3 BULLDOZER
● The machine adopts double-circuit electronically controlled hydrostatic drive system to ensure good load self-adaptability, loaded and in-situ steering capability, stepless speed regulation, and high flexibility and efficiency and realize outstanding construction performance in narrow sites.
● The chassis system features long ground length, high ground clearance, stable driving, and excellent trafficability. Depending on the specific working condition, the semi-U blade, U-blade, coal blade, straight tilting blade, environmental sanitation blade, rock blade, ripper, traction frame, and rear protective frame can be installed to achieve high operating capability. The standard LED working lamps of higher illumination intensity improve the illumination capability during nighttime operations to achieve higher safety and reliability.
● The chassis system features long ground length, high ground clearance, stable driving, and excellent trafficability. Depending on the specific working condition, the semi-U blade, U-blade, coal blade, straight tilting blade, environmental sanitation blade, rock blade, ripper, traction frame, and rear protective frame can be installed to achieve high operating capability. The standard LED working lamps of higher illumination intensity improve the illumination capability during nighttime operations to achieve higher safety and reliability.
