Lrs-350 series 350W switching power supply | ||||||||||
project | Technical index | |||||||||
output | DC voltage | 5V | 12V | 24V | 48V | |||||
Rated current | 60A | 29A | 14.6A | 7.3A | ||||||
Rated power | 300W | 348W | 350.4W | 350.4W | ||||||
Ripple and noise ① | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | ||||||
Ripple and noise | ±10% | |||||||||
Voltage accuracy | ±3.0% | ±1.5% | ±1.0% | ±1.0% | ||||||
Linear adjustment rate | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ||||||
Load adjustment rate | ±2.0% | ±1.0% | ±0.5% | ±0.5% | ||||||
Starting and rising time | 1500ms、50ms/230VAC 1500ms、50ms/115VAC(full load) | |||||||||
Retention time | 16ms/230VAC 12ms/115VAC(full load) | |||||||||
input | Voltage range / frequency | 90-132VAC/180-264VACSelect by switch / 240-370VDC 47Hz~63Hz | ||||||||
Efficiency (typical) ② | 83.50% | 85% | 88% | 89% | ||||||
Working current | 6.8A/115VAC 3.4A/230VAC | |||||||||
Impulse current | Cold start:60A/115VAC 60A/230VAC | |||||||||
Leakage current | <2mA 240VAC时 | |||||||||
protect | overload protection | 110% - 130% protection type: burping mode, automatic return to normal after removing abnormal conditions | ||||||||
Overvoltage protection | 115% - 145% protection type: close the output, restart and automatically return to normal | |||||||||
Over temperature protection | Protection type ≥ 90 ℃: burping mode, automatic return to normal after removing abnormal conditions | |||||||||
function | Fan on / off control | Rth3 ≥ 50 ℃ fan on ≤ 40 ℃ fan off | ||||||||
Environmental Science | Working temperature and humidity | -25℃~+70℃;20%~90RH | ||||||||
Storage temperature and humidity | -40℃~+85℃;10%~95RH | |||||||||
Safety regulations | Withstand voltage | Input output:3KVAC Input - Housing:2KVAC Output - Housing:0.5KVAC 1 minute | ||||||||
Insulation impedance | Input output, input shell, output shell :500VDC/100MΩ 25℃ 70%RH | |||||||||
Other | size | 215*115*30mm(L*W*H) | ||||||||
Net weight / gross weight | 760g/827g |
