Высококачественный гидравлический электромагнитный клапан HYDA 24 В Паркер блок D41VW021B4NJW91
- Категории: >>>
- Поставщик: Henan,Zhuoer,Electromechanical,Technology,Co.,Ltd.Henan,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Specifications
Hydraulic Valve Detailed Information
The pilot operated valves are available in 4 sizes:
D31DW NG10 (standard)
D31NW NG10 (high flow)
D41VW NG16
D81VW NG25 (for port diameter up to 26 mm)
D91VW NG25 (for port diameter up to 32 mm)
D111VW NG32
D31DW NG10 (standard)
D31NW NG10 (high flow)
D41VW NG16
D81VW NG25 (for port diameter up to 26 mm)
D91VW NG25 (for port diameter up to 32 mm)
D111VW NG32
All valves are piloted by a D1VW valve. Please see the separate ordering code for valves with position control.
The minimum pilot pressure must be ensured for all op erating conditions of the directional valve.
Additionally spools with a P to T connection in the de energized position need an external pressure supply
(external inlet) or an integral check valve.
(external inlet) or an integral check valve.
Product name | hydraulic valve |
Valve type | hydraulic directiona spool valve/hydraulic electromagnetic directional valve |
Material Quality | Cast Iron |
Pigment | black |
Actuation | Solenoid |
Nominal size | NG16 |
Mounting interface | DIN 24340 A16 / ISO 4401 / CETOP RP 121-H / NFPA D07 |
Mounting position | unrestricted, preferably horizontal |
Ambient temperature | -25...+60 |
Electromagnetic voltage | DC24V |
Max. operating pressure（bar） | P, A, B: 350; T: 210 (DC), T: 140 (AC) |
Fluid | Hydraulic oil according to DIN 51524 |
Fluid temperature | ~-20…+70 (NBR: -25…+70) |
Flow max.（L/min) | 300 |
