     Regenerated Rubber Close Mixing Mill Machine    is for producing compound rubber and supply to tyre rubber production line as its material.



Work Principle:

Spiral moving cutter of         Regenerated Rubber Close Mixing Mill Machine which is installed in the axis of rotation and fixed cutter which is installed,that they work with the relative motion. Water of rubber is reduced by their heat when machine do movement of cut & press, and then rubber mix together in average.


Function:

Regenerated Rubber Close Mixing Mill Machine       is useful equipment not only for reducing water, removing white spot, enhancing consistency from rubber, but also stir and mix several kind of rubber to make into a special rubber.

Main technical data:

Type	GJ-400	GJ-500
Rotational Speed of Spindle	30r/min	59r/min
Power	160kw	250kw
Diameter of Moving Cutter	400mm	500mm
Production Capacity	1.2t/h	2-3t/h
