New ball mill price/cement grinding ball mill machine/small ball mill



The mill is cylinder rotating device with girth gear and two chambers. The materials are fed to first chamber through hollow shaft through feeding device. There is stepped liner or waves liners and different size of balls inside this chamber. After finishing in first chamber, the materials will be fed to second chamber. There is flat liners and balls inside second chamber, which will grind the materials once again. After grinding, the powder will be discharged and then finish grinding works.

Product instruction





Instruction for Use

Shell
This ball mill is horizontal shell rotating device, mainly consist of shell, mill door and liner bolts. So we required to check the mill when shut down, especially to check the liners on shell and mill door.
Liner
The liners are used for protect shell in order to avoid damage to shell, please check liners regularly to avoid any loose because of bolts etc.
Diaphragm
Diaphragm is used to separate grinding media to avoid axial movement of media and large size move to next chamber. It can make suitable grinding for materials and control filling grade, material flow, and grinding speed inside mill.
Diaphragm plate is consist of central circle, feed cone, grate plate, lifting plate, liner, diaphragm support and blind plate. Please check if there is any loose, missing of bolts, to check the condition of grate plate and blind plate, if there is any crack or influence to grate plate and check if there is any movement of balls.
Main bearing
Bearing is used to bear the weight of rotated part also impact of grinding media. The mill is supported on main bearing by hollow shaft. There is bearing cover, watch hole, temperature gauge on bearing housing.
Feeding and discharging device
Feeding device is used to feed materials into mill, there is chute feeding device, screw feeding device and ladle feeding device. The discharging device is consist of discharging grate plate, guide cone, lifting plate, discharging cylinder, drive connecting tube,drum screen, discharging cover, coarse tube etc.
Drive device
Drive device is consist of speed motor, slow drive motor, slow reducer and speed reducer. Mainly check: if there is any overheat and noise of reducer oil pump. And check working condition of each elements such as pressure gauge, temperature gauge, and if there is any oil leakage, oil level and oil color of oil tank. Please adjust oil flow as per weather condition; check if there is any noise of main oil pump etc.



Company Introduction

Jiangsu Pengfei Group Co.,Ltd,was established in 1994 and with a registered capital of 51.3859 million yuan,is a hightech enterprise specializing in

undertaking overall contracting projects of designing, manufacturing, supplying, assembling, debugging and technical serving for industries like building materials, environmental protection, metallurgy,and mini cement plant and cement making machine.

Our products mainly consist of minicement plant,rotary kiln, ball mill, raw mill, slag mill, cement grinding equipment, preheating equipment,

 laterite nickel rotary kiln,cementmakingmachine, air swept coal mill, mining mill, autogenous mill,rolling machine,

 powder separator, vertical mill, crushing equipment, environmental protection equipment, cooling machine, drying equipment, fluidized bed furnace, compound fertilizer equipment, blending machine, granulator, vibrating screen, proportioning scale, conveyor, feeding machine, air slide, elevator, chemical evaporimeter, conditioning tower, electrical control equipment, liquid ammonia tank.

Jiangsu Pengfei Group Co., Ltd. is located in Nantong City which is in the north of Yangtze River delta economic metropolitan area. It connects Yellow Sea in the east and looks south to the Yangtze River. The company is the national famous building material machinery manufacturing and transporting base. The goods will be shipped to focus all over the world by the million tons of seagoing vessel will through the international Nantong Port and Shanghai Port. Ningqi Railway and Xinchang Railway connect here, and at the same time the coastal Highway and Haili Highway also link here. Because of its special harbor location advantages and manufacturing capacity, Pengfei Group has become the largest cement equipment manufacturing and exporting base in our national coastal areas.

The company has the great comprehensive ability to provide best quality services on turn-key basis with technology design, complete plant, erection and debugging,commissioning for the 10000tpd rotary kiln cement production enterprise.It can also undertake various projects abroad international bidding projects. It supplies complete equipments and technical services of grinding, calcination, crushing, dust collecting, conveying and lifting for the metallurgy, the chemical industry, the electrical power, the mine, the environmental protection enterprises, etc.



Why choose us







 Cetificate

 Shippment





300-8000 ton per day best price cement plant/cement machinery/cement plant
