Chassis Model | EQ6570K4AC1 | ||||||||
Gear Box | Model: 1700010-FF04; Specification: DF5S410; Dongfeng automobile transmission Co. Ltd | ||||||||
Clutch | Single,Dry,Diaphragm Spring,Clutch booster | ||||||||
Front Axle | Dongfeng Dana Axle(2.3T) | ||||||||
Rear Axle | Dongfeng Dana Axle(5T) | ||||||||
Suspension | Steel plate spring, Front:8/ Rear:10 | ||||||||
Steering | Mechanical | ||||||||
Brake | Double circuit pneumatic braking,Central drum brakes | ||||||||
Fuel Tank | 90L | ||||||||
Tire | 7.00R16-12PR | ||||||||
Battery/Generator | 6-QA-105/55A,70A | ||||||||
Others | Engine pre-heating device,Aluminum tank,ABS,Adjustable arm,Clutch booster,Dryer, | ||||||||
Body Structure | Semi-integral Body | ||||||||
Interior Trimming | Common Trimming | ||||||||
Doors | Middle & Rear pneumatic folding doors | ||||||||
Side Windows | Fastened type for upper, push-pull type for below, light green color | ||||||||
Windshield | Front: laminated glass with defroster & wiper; Rear: toughened glass | ||||||||
Rearview System | Manual steel-rack type rearview mirror; Inner mirror | ||||||||
Air-conditioner | N/A | ||||||||
Heating System | Common heater, 130 W, 2 air outlet, 25mm for water heating pipe | ||||||||
Defrost System | 24V, 180W, 2-gear, 25mm for water heating pipe | ||||||||
Audio-Visual System | N/A | ||||||||
Lamps | Front/Rear combination lamps | ||||||||
Wiper | Opposite-type electric wiper | ||||||||
Hatch Door | Horizontal side door for air filter, Steel stamping hatch, Luggage room in left sides. | ||||||||
Seats | 2+1 layout,23 seats,City seats with cushion, seat width: 400 mm | ||||||||
Paint | Domestic paint | ||||||||
Others | PVC floor,Flat floor,Fan,Safety hammer,120 A Camel brand storage battery,700A skylight,Knurling handrail with hand rings,passenger door emergency air escape cock,Air horn |
