Высокочастотный аналоговый маммографический рентгеновский аппарат серии

Application:

Mammography Unit is a X-ray apparatus involving in various advanced technologies,

specially designed for the diagnosis of mammary gland diseases. It is sensitive to

mammary gland lump, calcification, protuberance and carcinogensis and first-choice

apparatus for the image examination of mammary diseases in medical institutes.

Main Parameters:

1. X-ray Generator

Complete solid-state high-frequency high-voltage generator.

Generator Type: High Frequency Inverter 80kHz

Power Supply: Single phase 220VAC, 50/60Hz

Tube Current: 0-120mA

Radiographic Ratings: Large Focal Point 20-35kV/10-510mAs

Small Focal Point 20-35kV/10-100mAs

Power Rating: 6.2kW

2. X-ray Tube (Rotation Type)

Model: IAE C339V (Imported from Italy)

Focal Spot Size: Dual Focus 0.1/0.3mm

Target Material: Molybdenum (Mo)

Port Material: Beryllium (Be)

High-speed anode drive: 2800/1000rpm

Target angle: 10°/16°

Anode Heat Storage: 210kJ (300kHU)

Anode Cooling: Air cooling

Filtration: Mo(0.03mm),Al(0.5mm)

Optional Function: AEC Exposure Control

3. Radiographic Stand

C-ARM: Vertical Movement: 590mm

Center of electric rotating C-arm, automatic return function by one key

Automatically released after the exposure pressure settings display

Compression flexible stepless speed.

Max. pressure: 200N

Max. travel: 150mm

Rotations Deg:+175°~-180°

SID: 650mm

4. Cassette Image Receptor

18*24cm (24cm*30cm optional)

Bucky Device: 18*24cm Bucky drive mechanism,(24cm*30cm optional)

Grid Ratio: 5:1, 30 Line/cm

5. Line Voltage

220Vac@25A, Single phase

6. Weight and Size:

240kg(Gross weight: 340kg)

L*W×H: 940mm*560mm*2000mm
