h2o portable welding machine price oxy hydrogen copper aluminum welding machine



The Technical Data

Small Portable

Model Number	OH100	OH200	OH300	OH400
AC Voltage Requirement(V)	220/110	220/110	220/110	220/110
Phase	single	single	single	single
Power Consumption(kw/h)	0.4	0.8	1.2	1.4
Max. Gas Output(L/h)	100	200	300	400
Max. Working Pressure(kg/cm2)	2	2	2	2
Max. Water Consumption(L/h)	0.06	0.11	0.17	0.23
Water Feed	manual	manual	manual	manual
Flame Modifier Feed	manual	manual	manual	manual
Dimensions-L*W*H (mm)	390*250*510	450*250*510	590*250*510	710*250*510
Gross Weight(kg)	15	20	24	28
Ventilation Space Requirement(mm)	200 in each direction	200 in each direction	200 in each direction	200 in each direction



Machine advantages and features

1. Easy and safety operation

The h2o portable aluminum welding machine / hho welding machine produce oxy-hydrogen gas by automatic way, gas cylinder is not required any more. Turn on to produce gas and shut down to stop producing. Machine will shut down automatically when the gas pressure is too high (if gas output can not be used up). Machine will turn on auto when the gas pressure is not enough. The gas output is adjustable.



2. Welding fast

The oxy-hydrogen flame temperature is high up to 2800 degree, it can heat the welding spot to melting point fast in about 1 second to finish welding.



3. High welding precision

The flame is concentrated, it can achieves welding of precise devices.



4. Smooth welding spot

Oxy-hydrogen flame combustion doesn't form carbide, so there is no black spot, avoid the second treatment of cleaning and polishing.



5. Environment friendly

h2o portable aluminum welding machine / hho welding machine 's  fuel comes from water, there is water vapor after combustion, no any harm done to environment.



6. Energy saving

h2o portable aluminum welding machine / hho welding machine saves energy cost over 30% compared with other gas welding way.Adding the oxygen cost, it will save cost over 40%.



More applications

1.Welding

(1) Electronic Industry



For welding enameled wire, computer wire peeling, LED wafer, flame-treating circuit board thermocouple and platinum resistor leading wires.



(2)  Medical Industry

For denture welding. For welding metal fittings and mending sand holes in dentistry.No-carbon flame disinfection and glass seal.



(3)  Laboratory

For welding of laboratory teaching, providing convenient, safe and clean oxy-hydrogen flame.



(4)  Jewelry Industry

For welding kinds of chain and string which are made of platinum, gold, silver, copper, stainless steel, etc. For mending tiny sand holes on jewelry casting and jewelry repairing(reforming,casting,welding).



(5)  Others:

Instrument welding, Air-condition copper pipe welding, Automobile exhaust pipe welding, Fishhook welding, Storage battery tinplate welding, lighting hardware welding and etc.



2.Cutting

Large oxyhydrogen generator/HHO generator can be widely used in Carbon Steel Cutting and continuous casting slab cutting of steel plant.



3.Heating and Sealing

(1)  metal and nonmetal heating

(2)  glass tube sealing, quartz glass tube sealing

(3)  ampoule bottles sealing



4.Polishing:Organic glass/Acrylic polishing

5.Others





















Okay Energy Equipment Co., Ltd which is the biggest supplier of oxy-hydrogen generator in China,we have

researched and produced hho generator for more than 13 years. During these years,it has been perfected

continuously and has been mature now. We have authorized CE , ISOcertificate and many of own patents

successfully.



HHO generator adopts water electrolysis to produce mixed oxygen and hydrogen gas which flame temperature

is up to 2800 degree.It does not need any fuels, just some water and a bit of electricity. So it is high efficient

and very economical.
