Product Description

8L Welding Water Cooler for TIG Welder and Plasma Cutting Mach
Model: WS-8L

\t
Model
\t
WS-5L
\t
WS-6.5L
\t
WS-7.5L
\t
WS-8L
\t
WSA-10L
\t
WS-15L
\t
Voltage
\t
1x230V, 50/60Hz
\t
1x230V, 50/60Hz
\t
1x230V, 50/60Hz
\t
1x230V, 50/60Hz
\t
1x230V, 50/60Hz
\t
1x230V, 50/60Hz
\t
Cooling power
\t
1.1kw
\t
1.6kw
\t
1.1kw
\t
1.5kw
\t
1.6kw
\t
1.1kw
\t
Pump power
\t
370W
\t
370W
\t
370W
\t
370W
\t
370W
\t
370W
\t
Output flow
\t
1L/min
\t
1L/min
\t
1L/min
\t
1L/min
\t
1L/min
\t
1L/min
\t
Max. pressure/Head
\t
0.30MPa/(35m)
\t
0.30MPa/(35m)
\t
0.30MPa/(35m)
\t
0.30MPa/(35m)
\t
0.30MPa/(35m)
\t
0.30MPa/(35m)
\t
Water capacity
\t
5L
\t
6.5L
\t
7.5L
\t
8L
\t
10L
\t
15L
\t
Operation temperature
\t
-20ºC~60ºC
\t
-20ºC~60ºC
\t
-20ºC~60ºC
\t
-20ºC~60ºC
\t
-20ºC~60ºC
\t
-20ºC~60ºC
\t
Gross Weight
\t
13kg
\t
14.5kg
\t
14kg
\t
16kg
\t
14kg
\t
21kg
\t
Packing Size(L*W*H)
\t
560*260*245mm
\t
590*320*270mm
\t
600*258*240mm
\t
456*253*328mm
\t
610*370*250mm
\t
560*380*580mm

● Light weight, compact design and easy to use.
● NSK bearing is applied on pump.
● The material of shaft seal is Polythene, and its service life is over 10 years.
● The shaft is made of stainless steel.
● The material of refrigerator is copper.
● The impeller is made of copper alloy.
● High performance on water anti-leakage;
● Good performance of Prevent scale in vortex water pump;
● Water level is visible outside through window.
● The water filling port is inclined forward to facilitate water injection;
● The cooling capacity increased by 30% compared to the Equivalent product.

Detailed Images
Packing & Delivery
