shantui bulldozer sd32 with cummins engine 235kw 10cbm blade capacity
Technical Feature
1. Chongfa NTAA855-C360S10 engine is equipped with exhaust gas turbocharger, featuring strong power and high efficiency and energy-saving, and can work normally even in the highlands as high as 3,600m. Depending on the customers’ demands, the option Cummins and Weichai engines are available.
2. The high reliability power shift transmission, the stable hydraulic torque converter, and two-stage spur gear final drive feature high power transmission capacity and efficiency and high productivity.
3.The independent engine water tank, the chassis oil cooler, and the water-air intercooler integrated in the Chongfa engine provide prominent cooling performance and simple maintenance operations to guarantee the continuous working of the machine.
4.The standard straight tilting blade features powerful cutting force and the single-shank and three-shank rippers of adjustable penetrating angle can be used for the ripping of clay and frozen earth as well as the stripping of hard working faces, such as gravel and hardened salt mine.
Performance Parameters
| Length × width × height (mm) (excluding ripper) | 8560×4130×3640(including ripper) | Operating weight (t)(excluding ripper) | 37.2 |
| Engine model | NTA855-C360S10 | Net power/rated speed (kW/rpm) | 235/2000 |
| Ground pressure(Mpa) | 0.105 | Blade type | Straight tilting blade Angle blade Semi-U blade |
| Blade capacity(m3) | 10 for straight tilting blade 6.2 for angle blade 11.7 for Semi-U blade | ||
We also can supply other types, standard type, wetland type, coal type, sanitation type, mechnical type:
If you want to know more details, please contact me as following:
