FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic)
Layer No.
1 - 30 Layers
Board thickness
0.0075"(0.2mm)-0.125"(3.2mm)
Board Thickness Tolerance
±10%
Copper thickness
0.5OZ - 5OZ
Impedance Control
±10%
Warpage
0.075%-1.5%
Peelable
0.012"(0.3mm)-0.02”(0.5mm)
Min Trace Width (a)
0.005"(0.125mm)
Min Space Width (b)
0.005"(0.125mm)
Min Annular Ring
0.005"(0.125mm)
SMD Pitch (a)
0.012"(0.3mm)
pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b)
0.027"(0.675mm)
Regesiter torlerance
0.05mm
Min Solder Mask Dam (a)
0.005"(0.125mm)
Solder mask Clearance (b)
0.005"(0.125mm)
Min SMT Pad spacing (c)
0.004"(0.1mm)
Solder Mask Thickness
0.0007"(0.018mm)
Hole size
0.01"(0.25mm)-- 0.257"(6.5mm)
Hole Size Tol (+/-)
±0.003"(±0.0762mm)
Aspect Ratio
6:01
Hole Registration
0.004"(0.1mm)
HASL
2.5um
Lead free HASL
2.5um
Immersion Gold
Nickel 3-7um Au:1-3u''
OSP
0.2-0.5um
Panel Outline Tol (+/-)
±0.004''(±0.1mm)
Beveling
30°45°
Product Range
4-28 layer of high-precision impedance, blind & buried layers, HDI boards, high frequency board, halogen-free boards, high-TG boards, aluminum, copper, iron base and ceramic-based circuit board, 1-6 layer flexible circuit board ( FPC) and rigid-flex flexible board, and other high-tech products.
