1.54 inch 128x64 30pin 4-wire SPI I2C monochrome white oled

Описание и отзывы

Характеристики



1.54 inch OLED / small OLED display module/OLED with 128*64 resolution

Item	1.54 inch OLED small OLED display module with 128x64 dots
Model name	KWH0154UL03
Display Mode	Passive Matrix
Resolution	128 x64
Display Color	white, optional blue
Drive Duty	1/128 Duty
Interface	Parallel / 4-wire SPI, I2C
Panel Size	42.07x27.22x1.45mm
Active Area	35.052x17.516mm
Module Costruction	COF
Power Supply Voltage	2.4~3.5V
Frame Rate	100 Frames/Sec
Brightness	90cd/m2
Folding Ability	Folding Type
Assembly	Connector
Operating   Temperature	-40~70°C
Storage Temperature	-40~+85°C
