Hot sell  sms modem pool 16 port sms blaster / 16 port gsm modem  bulk sms



The GSM Modem is actually a kind of equipment used for sending and receiving SMS. It needs a mobile phone SIM card to support just the same as we use cellphone. In the need to send Bulk SMS, put sim card into the device, link power and connect a pc through the USB cable. Then we can realize the function of the sending and receiving SMS by using the relevant computer management softwarewe.

Product Feature

  1, can insert 16 SIM cards(big or small)

  2, connection with the computer through a data line can be integrated with USB
 3, Each channel with separate power switch
 4, Each individual module can be demolished
 5, industrial chassis, elegant shell

6.IMEI CHANGE
7, support  API and AT
8,dual/quad band

Specifications
1.Professional and factory price
2.Great customer service and fast shipment
3.One year free warranty

evice

SMS blaster/ 16 ports SMS blaster/ bulk sms sending device

SMS blaster/ 16 ports SMS blaster/ bulk sms sending device

SMS blaster/ 16 ports SMS blaster/ bulk sms sending device

Key Feature:

     Just like 16 single-channel equipments work at the same time
     can insert 16 SIM cards(big or small)
     connection with the computer through a data line can be integrated   with Serial 16
     industrial chassis, elegant shell
     GSM frequency: 2G/3G/4G
     Wireless access to internet
     Comply with GSM phase2 standard
     Dual-band/Quad-band(optional)
     RS-232/USB interface(optional)
     Optional MMS,data,voice function

 Can send and receive English SMS in bulk

Basic Feature:
     Asynchronous, transparent or non-transparent, to a maximum    14400 bits / s
     Baud Rate : 300-115200 bits / s
     Automatic baud rate: from 2400 to 19200 bits / s
     Fax support three
     Switched voice and fax
     V.42, V.42bis
     GPRS compatible
     WAP compatible
     SMA Antenna Interface
     SIM Card Outlet
     Power connector
     RS-232, the Mini-DB-9 connector
     AT command control ( GSM 07.07 and 07.05)

Application:
   1. Large shopping malls, supermarkets

2.Professional market, large wholesalers

3.Large hotels, large-scale entertainment

4.Large agencies

5.Transport, logistics industry

6.Large enterprises, and institutions

7.Large hospitals, large bookstore

8.Newspaper, television and radio stations

9.Oil Company ( other chain business model)

10.Government agencies or large township

Technical parameter

Supported Operating Systems:

Windows 7/ Windows Vista/ Windows XP/ Windows Server 2003/ Windows 2000/..ect





16 ports sms modem pool/gsm sms sending device

Model	SK 16 ports SMS Blaster
Module	Quectel M35 /M26 UG96 EC25
Ports	16 ports SMS Blaster
Frequency	2G/3G/4G
SMS	MT, MO, CB, Text and PDU mode
Functions	SMS; MMS; USSD; IMEI Change; At Command; Make and Answer Call; GPRS
Headset	Support, u can use it to make a call and answer a call through AT Command
Transmit-Receive Rate	750-1000 SMS/SIM/Hour
AT command control standards	GSM 07.07, 07.05
GPRS Class 12 Rate	85.6 kbps ( Uplink & Downlink)
Antenna	50 Ohm, 3db
Input	AC 110-220V, 50-60Hz
Output	DC 12-24V

How to change the  module imei

 1. Use putty to login the module

 2. Input the at command ATE1 to echo display

 3. //WRITE:AT+EGMR=1, 7, "359231033480797" this at command will change the module imei to

 359231033480797, and pls notice that you have to use the correct imei number if not the imei will be

 changed back to factory after reboot.



 3. How to make a call

 1. Login the module and plugin the earphone in the module.

 2. Input the at command ATE1 to echo display

 3. Use at command ATD to make a call. Such as you want to dial 10086 then you need fill at command ATD10086; then you can hear the ring from the earphone. You can use at command ATH to handup a call



How to use

1, Insert Sim card into device

SMS blaster/ 16 ports SMS blaster/ bulk sms sending device





SMS blaster/ 16 ports SMS blaster/ bulk sms sending device

1. Q: What frequency do this SMS Modem support?

A: 2G/3G/4G

2. Q: Can you tell me the functions of SMS Modem?

   A: It can be used to send SMS, MMS in bulk. It also support GPRS, USSD, DAILING, AT command.

3. Q: Where can the SMS Modem used?

   A: The main function of SMS Modem is sending SMS in bulk, so it can be used to send notification, such as market promotion, Notification of Government, school, agent...

SMS blaster/ 16 ports SMS blaster/ bulk sms sending device

4. Q: I’m a freshman to this device, is there any User Manual or Technician can help me when i first set up the device?

   A: We have PDF User Manual for our device, and our technician is 24 hours on duty, they would help u to set device up, and install free software SMS Caster 3.6 for u. And teach u how to use it hand by hand. If u have any doubt about it, u can contact our

SMS blaster/ 16 ports SMS

5. Q: How is the quality and after-sale service?

   A: The warranty of all our products last 12 months. Were there any problems about our products quality, we could change a new product for you in any circumstance.

SMS blaster/ 16 ports SMS blaster/ bulk sms sending device

6. Q: Are there any other products in your company?

   A: Our company mainly produce VOIP Gateway, SIM Bank, IP Phone, fxs, Voice Recorder etc. . If there were any needs, please contact us freely.
