Вертикальный и горизонтальный револьверный фрезерный станок X6336WA TTMC с

Цена:150 675,80 ₽ - 452 027,40 ₽*

Стоимость в USD (на сегодня):Узнать

Количество:

Product Description

Item	X6336WA Milling Machine
Spindle taper	ISO40(V) ISO50(H)
Distance from spindle to table	135-585mm
Distance from horizontal spindle to table	0-380mm
Distance from spindle to column	200-700mm
Spindle speeds	(16steps))75-4660r.p.m(V) (12steps))30-1800r.p.m(H)
Spindle travel	127mm
Feeding of quill	(3steps)0.04 0.08 0.15
Max drilling capacity of auto-feeding	15mm
Max rotaions angle of table	45degrees
Head movement(left/right)	45degrees
Table size	1600*360 mm
Table travel(horizontal/cross/vertical)	1000390450mm
Feeding range of longitudinal cross travel	(8steps)30-630mm/min
X-axis rapid feed speed	2000mm/min
Z-axis rapid feed speed	(8steps))18-300mm/min /630max
Z-axis motor power	1500W
Max weight of workpiece	450kg
T-slot number /width/distance	3/18mm/70mm
Horse power for main motor	5HP(V)4.0KW (H)
X axis driving motor	1500W
Overall dimension	218019502380
N.W./G.W.	2500/2680KG
