FST100-7102 Wireless Liquid Underground Water Level Controller Indicator Monitor
Our Advantages
Why Choose Our Firstrate?
♦ Focus on sensor production for more than 50 years;
♦ Factory Outlet, Low price;
♦ 12 months free repaire warranty;
♦ Firstrate products have past CE, ROHS, ISO9001 etc.
Product Description
| Product Introduction | |
| FST100-7102 Wireless Liquid Underground Water Level Controller Indicator Monitor adopts high quality imported pressure sensitive core body, and is equipped with ultra low power consumption microprocessor and high precision sensor signal conditioning circuit. It is added to remote transmission module and adopts LoRa transmission mode to realize on-site monitoring data to the cloud. Wireless transmission. The customer can obtain the measurement data by logging in to the relevant website through the Internet PC or the mobile terminal, and realize the statistics and analysis of the collected data, and form the report and the data curve, which is intuitive, accurate and efficient. The product is mainly used in hydrological monitoring and control systems, water pipe network monitoring, reservoir high and low liquid level monitoring, building automation, constant pressure water supply systems and other automation and inspection systems. | |
| Product Features | |
♦ Low power design, lithium battery / power supply optional ♦ LoRa wireless transmission method | |
| Applicable Scope | |
♦ Industrial process level measurement and control ♦ Other automated system level measurement and control | |
| Product Specification (Technical Parameters) | |
Range range (mH2O) | 0~1...50 meters |
| Measurement range | -100kPa~0~20kPa...60MPa |
Power supply voltage | 3.6V battery power supply 12~30VDC external power supply |
Accuracy | ±0.5 %FS ±1%FS |
Temperature compensation | -10~+70℃ |
Working temperature | -20~+60℃ |
Long-term stability (1 year) | ≤0.2%FS |
| Overload pressure | 200%FS |
Working frequency band | 470MHz/868MHz |
Sampling frequency | 10s~12h can be set (default 10s) |
Sending frequency | 1min~1440min can be set |
| Communication Protocol | Private Protocol/LoRaWAN (Class A, OTAA Mode Activation) |
Protection grade | Contact unit: IP68, Industrial housing: IP65 |
Housing Material | Liquid Contact Material: 304 Stainless Steel, Industrial Housing: Aluminum Die Casting or ABS |
Power consumption current | Sleep current: ≤20uA, sampling current: ≤5mA (for 1s), |
current | Average communication current: ≤60mA (for 15s), online current: ≤10mA (for 60s) |
Battery capacity
| 12000mAh |
Display mode | 6-segment LCD display |
Storage environment | Temperature -40~+80°C, humidity: 0~95%RH |
