Монитор камеры Lilliput A8S IPS 8 9 дюйма 3D-LUT 4K HDMI

4K HDMI input & loop output,
3G-SDI input & loop output,
1920x1200, Full HD resolution,
350cd/m² high brightness,
800:1 high contrast,
 Peaking, 3D-LUT

Function:

Center Marker, Aspect Marker, Check Filed, Underscan, Scan, Aspect, DSLR, Freeze, Peaking, False Color, Exposure, Histogram, Level Meter.

Center Marker: ON, OFF
Aspect Marker: OFF, 16:9, 1.85:1, 2.35:1, 4:3, 3:2
Safety Marker: OFF, 95%, 93%, 90%, 88%, 85%, 80%
Marker Color: Red, Green, Blue, White, Black
Grid: OFF, ON
Marker Mat: OFF, 1, 2, 3, 4, 5, 6, 7
Thickness: 2, 4, 6, 8

Scan: Aspect, Pixel To Pixel, Zoom
Aspect: Full, 16:9, 1.85:1, 2.35:1, 4:3, 3:2
Underscan: OFF, ON
Check Field: OFF, Mono, Red, Green, Blue
Zoom: x1.5, x 2, x 3, x 4
Freeze: OFF, ON
DSLR: OFF, 5D2, 5D3
Language: Switch between English and Chinese.
OSD TIMER: Select the displaying time of the OSD. It has 10s, 20s, 30s preset to choose.
Image Flip: The monitor support H, V, H/V three preset Flip modes.
Back Light: Adjusts the level of the back light level from 0-100. If the back light value is increased, the screen becomes brighter.
