Specification:
| Motor | 10 inch Brushless Gearless motor |
| Hallsensor | YES (5 hall sensor wires) |
| Brake type | V/Disc brake |
| Motor wheel size( include the tire) | 10 inch |
| Tire Model | 10*4.00-6 Vacuum Flat ( Road) tire |
| Tire Width | 78mm |
| Max Torque | 15 N.M |
| Rated power | 350W-500W |
| Rated voltage | 24V/36V/48V |
| Speed | 12---45km/h |
| Rotating speed | 250---1000 RPM |
| Load Weight | 100-120 kg |
| Open file | 104 mm |
Has a high speed and RPM. It is suitable for riding on the ground, but can't climb a steep slope.
Material:
1. wheel: standard international A356 aluminum heat treatment.
2. magnetic steel: standard 38H
3. iron core: DW350 lamination
4. Hall: Honeywell can resist high temperature: 150
Note:
1.Single shaft motor shaft is non-threaded
2.All the shipping way won't allow the item with gas go to there aircraft. So all the wheels are without gas to arrive to you. When you get it, please inflate the wheel firstly.
Packing List:
1* 10 Inch single shaft hub motor(with flat tire)
