High speed razor wire production machine

Razor barbed wire machine,also called blade barbed wire machine.

It is composed by two production lines:Punch line and assembly Line.Punch line is used to punch the Galvanized sheet becoming wire with blade shape. And the assembly Line combine inner round with blade shape wire together.

This type has advantages of easy operation,easy maintain,high speed and low energy consumption.

Model	25T	40T	60T	Coiling machine
Voltage	380V,50HZ or according to client's voltage
Power	2.2kw	2.2kw	7.5kw	1.5kw
Producing speed	220-280m/h	220-280m/h	220-280m/h	2 Ton/8h
Pressure	250Ton	25Ton or 40Ton	60Ton	--
Thickness of sheet	0.5±0.05(mm)	0.5±0.05(mm)	0.5±0.05(mm)	--
Diameter of wire	--	--	--	2.5mm
Material of sheet	GI	GI and stainless steel	GI and stainless steel	--

Blade types for you to choose:

Style	Barb length	Barb width	Barb space	Steel tape shape	Punch Capacity
					By 25T	By 40T	By60 T
BTO-10	10±1 mm	13±1mm	26±1mm		9 strips	--	--
BTO-12-1	12±1mm	13±1mm	26±1mm		9 strips	--	--
BTO-12-2	12±1mm	15±1mm	26±1mm		9 strips	--	--
BTO-18	18±1mm	15±1mm	33±1mm		9 strips	--	--
BTO-22	22±1mm	15±1mm	48±1mm		9 strips	--	--
BTO-28	28±1mm	15±1mm	49±1mm		7 strips	9 strips	11 strips
BTO-30	30±1mm	18±1mm	49±1mm		7 strips	9 strips	11 strips
BTO-60	60±1mm	32±1mm	96±1mm		--	5 strips	5 strips
BTO-65	65±1mm	21±1mm	100±1mm		--	5 strips	7 strips

 Q: Where is your factory located?
A: Our factory is located in Anping county, Hebei Province of China. The nearest airport is Beijing airport or Shijiazhuang airport. We can pick you up from Shijiazhuang city.

Q: How many years are your company engaged in the wire mesh machines?
A: More than 25 years. We have our own technology develop department and testing deparment.

Q: Can your company send your engineers to my country for machine installation, worker training?
A: Yes, our engineers went to more than 100 countries before. They are very experienced.

Q: What's the guarantee time for your machines?
A: Our guarantee time is 2 years since the machine was installed in your factory.

Q: Can you export and supply the customs clearance documents we need?
A: We have much experience for exporting. And we can supply the CE certificate, Form E, passport, SGS report etc, your customs clearance will be no problem.
