Shenzhen LiLuTong Technology Co., Ltd was established in year 2001, rang of products security promoting, developing for security products, expecially LPCB(Certificat No. : 1383a/1383b) fire resistant cable. UL (Certificate No. :E502147) fire alarm cable, elevator cable and flexible cables.
LLT' skilled production team follows the standard of ISO9001:2000 quality system strictly for making sure every produure is out of mistakes. LLT products are appproved by LPCB, CCC, CE, FCC, SGS, VDE,UL, and compliant with the ROHS standard.
Detail Spec. of LPCB
Our fire resistant cable got the Brithsh BRE company's LPCB authentication.
BS7629
BS6387
EN 50200
BS5839-1
Standard 60
CWZ
PH120
Standard
1.BS7629-1 : Methood of test for resistanceto fire of upprotected small cable for use in emergency circults.
2.BS 6387 : Performance requirements for cable required to maintain circuit integrity under fire conditions.
3.EN 50200 : British Standard Specification for 300/500 fire resistant cable for use in emergency circuits.
4.BS 5839-1 :Statres standard fire resisting cable's should meet the PH30 classification when tested in
accordance with additionally the 30 minutes survial time when tested in accordance with Annex E of
standard.
Note: LLT FR-Multi core cable meet all the standards in LPCB requirement
LPCB approved cable performance & applicatoion:
Resistance to fire at 950oC for 3 hours, LSNH out jacket keeps the low smoke
without toxic gas remaining
The integrity of the circuit, ensuring people enough survival period in the fire desater
1. Water Spray
2.Sprinkler
3.Fire Alarm System
4.Dry Riser
5.Vales
6.Foam Systems
7.Smoke Detector
8.Exit Light
9.Fire Men Garments
Product specificatio
Formation: 2cores, 3cores or 4 cores
Section: 1.0mm Sq, 2.5mmSq, 4.0mmSq
Section: 1.0mm Sq, 2.5mm Sq, 4.0mm Sq
Conductor: Top quality bare copper
Insulation: Top quality Silicom Rubber E12
Jacket: Special Low smoke zero halogen thermoplastic compound
Withstand heat: Special mica tepe
Shield: Top quality glass fiber tape or AL foil( Option)
Drain drws: Tinned copper
Vated Voltage: 300/500V
related products
Fireproof cable are suitable for high rese building, entertainment venues and many high quality and high secure
construction projects, they are application for fire protection systems for fire elevators, fire pumps, fire alarm, smoke
exhaust systems, emergency light and fire danger zones. power supply line for safe facility in high temperature
and special requirements.
FAQ
1. Does LLT factory have certification?
Yes, LLT' skilled productioon team follows the standard manufacturing process which is ISO9001 QualitySystem
strictly for making sure every procudure is out of mistakes.
2.Does your company's products have certification?
Yes, LLT products have approved by British Standard LPCB, CCC, CE, FCC, SGS, VDE and UL, and compliant with the ROHS standard.
3.When can I get the price and effectiveness?
We usuall quote with in 6 hours, If you desperately need the price, please contact us or send us an EMAIL. we
can handle the priority of your inquiry. Usually within a day, It's valid for 10 days
4. I didn't find the product specifications I need on this page
Dear friends, you can contact us by email In addition, we provide customized services. Warmly welcom to
