Двухсторонний поворотный Пневматический поршневой привод певицы серии
- Категории: Pneumatic Parts >>>
- Поставщик: ZHEJIANG,HEARKEN,FLOW,EQUIPMENT,CO.,LTD
Поделиться:
Описание и отзывы
Характеристики
Description
HPAC Scoch yoke Pneumatic actuator is prelubricated and tested to a min one million Actuators are avaiIable double acting and spring return models,Its meet international ISO5211 standards for easy vale mounting and replacement Visual position indicator will monitor the open and closed positionWorking Pressure : From 2 bar up to 8 bar.
-Standard Temperature: -20℃+80℃
-Low Temperature: -50℃+80℃
-High Temperature: -15℃+150℃
-Low Temperature: -50℃+80℃
-High Temperature: -15℃+150℃
S/N | Desription | Material | S/N | Desription | Material |
1 | Cylinder | Aluminium Alloy | 18 | Piston ring | Engineering Plastics |
2 | Piston | Aluminium Alloy | 19 | Piston O-ring | NBR |
3 | Shaft | Alloy Steel | 20 | Piston support chip | Engineering Plastics |
4 | Yoke | Alloy Steel | 21 | Connection plate O-ring | NBR |
5 | Piston pin | Alloy Steel | 22 | Connection plate | Aluminium Alloy |
6 | Yoke pin | Alloy Steel | 23 | Plate socket screw | Stainless Steel |
7 | Bearing | Alloy Steel | 24 | Cover socket screw | Stainless Steel |
8 | Upper circlip | Stainless Steel | 25 | Nut O-ring | NBR |
9 | Lower circlip | Stainless Steel | 26 | Screws | Stainless Steel |
10 | Upper washer | Engineering Plastics | 27 | End Cover Seal Ring | NBR |
11 | Lower washer | Engineering Plastics | |||
12 | Upper shaft O-ring | NBR | 101 | Cover | Aluminium Alloy |
13 | Lower shaft O-ring | NBR | 102 | Spring | Spring Steels |
14 | Upper shaft bearing | POM/Graphite Copper Bushing | 103 | Lower Spring Washer | Aluminium Alloy |
15 | Lower shaft bearing | POM/Graphite Copper Bushing | 104 | Spring Shaft | Stainless Steel |
16 | Upper piston bearing | Engineering Plastics | 201 | Double Acting End Cover | Aluminium Alloy |
17 | Lower piston bearing | Engineering Plastics | 202 | Set Screw | Stainless Steel |
Q: What is your main products?
A: Our main products are Pneumatic Actuators, Electric Actuators And Valve Accessories.
Q: Are you a trader or manufacturer? Do you have factory ?
A: We are the actuator manufacturer,we have ability to do the customization products with experienced team, And we have own factory and production line.
Q: How do your make the quality guarantee?
A: We have our own quality control ,every product will be under controlled and tested before delivery ,and we also provide 18 months guarantee.
Q: When can I receive the Price ?
A: We will give the Quotation Within 24 hours after we get your inquiry .Or Your can call us if its quite urgently.
Q: How to order our valve actuators ?
A: Please send us your inquiry by Email, Whatsapp,WeChat etc. we need to know the following information before giving the formal Quotation.
1) Product information in details, Quantity, Other requirements .
2) Delivery time required .
Q: How can I get a sample to check your quality ?
A: Contact with our sales expert to arrange the sample delivery. Please send us the details of the sample before placing the order.
Q：Shall we pay the sample cost and transportation cost ?
A: We will provide the sample by free of charge. Your will bear the freight cost.
Q: How long to prepare the sample ?
A: Most of our products are under regular production and some of them we keep in stocks.
Q: How to delivery the sample to our place?
A: Your can provide your forwarders contact if any, or we will arrange it.
Q: What about the delivery date if we place the formal order ?
A: Usually it takes 15~20 days on the production .We know that on-time delivery is very crucial to our customers to meet dead-lines.
We monitor and expedite our supply chain to ensure that we delivery our products to our customers on-time . All the time.
