HZS series Concrete Batching Plant belongs to compulsory and efficiency equipment. It includes JS concrete mixer, PLD batching machine,cement silo,conveying system and control system.And also has the characteristic of mixing well, high productivity, highly automated, high flexibility, convenient operation, and good stability.
Concrete mixing plant concrete mixing plant can be widely used in construction projects like buildings, roads, bridges, high way roads, docks, airport, water projects, hydropower station, etc. They can also be used in fibre reinforced concrete unit factories and used as commercial cyclone cement concrete mixing plant to sell high quality concrete to different buyers.
Technical Parameter of YHZS35 Concrete Batching Plant
Model | YHZS35 |
Capacity | 35M3/H |
Max.Dragging Speed | 40km/h |
Discharging Height | 3800mm |
Concrete Mixer | JS750 |
Max Aggregate Size | 80/60mm |
Batching System | PLD1200 |
Storage Bins Quantity | 2 or 3 or 4 sorts |
Name: Mixing System portable Mobile 35m3/h YHZS 35 concrete batching mixing plant
JS twin-shaft concrete mixer can be chose according to client;
Discharging height is 1.7-3.8(m);
Pneumatic/Hydraulic Control;
Easy replacing of wearing parts, such as liner plates.
Name: Cement system portable Mobile 35m3/h YHZS 35 concrete batching mixing plant
Capacity of 50t, 100t, 150t and 200t are optional, with the cement smoke filter;
One-piece/Modular tank are optional.
Name: Lifting System portable Mobile 35m3/h YHZS 35 concrete batching mixing plant
Normally Lifting hopper be used in mixing plant less than 90m3/h, and belt conveying system be used in mixing plant
Name: Control System portable Mobile 35m3/h YHZS 35 concrete batching mixing plant
PLC/Centralized Control with the emergency stop button and safety control key;
TV monitoring systems for batching machine, concrete mixer and discharging mouth are optional for clients.
The wide product range enables us to provide our customers with stand-alone machines or complete processing plants. Based on our customers' request and budget, our experts make efficient, reliable solutions. Following customers' order we produce strictly, what's more, before placing the order every customer has the chance to visit working machines or complete plant in the site.
To ease the trip for every visitor to China, in particular the first-time visitor, we provide FOR FREE all relevant visitor-friendly services including invitation letter preparation, hotel reservation, airport pick-up, incity transportation, and sightseeing guide, etc.
Experienced technicians guidance is available on the phone, and on the internet. One or more engineers will be dispatched to the quarry site to help install the customers' plants. Necessary training about machine daily maintenance to local workers is provided also.
After-Sales department is made of well-trained employees and installation engineers, the installation engineers are special and professional members of company, they are now strategically located home and abroad, working for our customers.
We are supply the spare parts for life time.
