1200 degree High temperature tube Furnace/industrial lab tube furnace for sintering test
Product Description
SK2-2-12TPA2 tube furnace with silicon molybdenum rods as heating element, using double shell structure and intelligent temperature control system of thyristor control, phase shift trigger, furnace using 1700 type of polycrystal alumina fibre materials imported from Japan, double layer between the furnace shell is equipped with air cooling system, can quickly rises to cool, USES the soft start of constant flow control, extend the service life of heating element. Balanced &energy-saving temperature control precision, temperature field, simple operation, quick elevating temperature rate, low energy consumption.
The characters:
- 30 Segments Programmable and PID temperature controller to make the operation more easy and simple.
- Furnace Chamber is made of Most advanced Alumina ceramic fiber to keep the better heat preservation .
- Double shell with fan cooling to make the shell temperature close to the room temperature.
- Integrated double circuit to make the furnace more safe , stable and reliable.
- Humanized design and advanced technical to make the furnace more beautiful and durable.
- Max vacuum can up to -0.1MPa, also can be Customize according to your request.
| Brief Introduction | XY vacuum tube furnace use quartz tube or High purity Al2O3 ceramic as furnace chamber. Working range is from 800Celsius to 1600Celsius. Precise and advanced auto temperature controller, high temperature accuracy, easy operation, excellent heat-insulation effect, symmetrical temperature uniform, XY tube furnace are widely used in the labs of university and Research Institutions, also used in factory for production. | |
| Technical Data | Style: | SK2-2-12TPA2 |
| Standard Working Temperature | 1100.C ( continuous ) | |
| Maximum Working Temperature | 1200.C ( < 3 hrs) | |
| Inside Chamber Size | Customizable | |
| Temperature Control | 30 steps programmable and PID automatic control | |
| Heating Rate | 0~10.C/ min (suggestion:=/<10.C) | |
| Temperature Accuracy | +/- 1.C | |
| Working Voltage | AC 220V Single Phase 60/50 Hz (or according to your requirement) | |
| Heating Element | Fe-Cr-Al resistance wire | |
| Max.vacuum: | -0.1Mpa | |
| Thermocouple | K type | |
| Max.Power | 2 KW | |
| Standard package included with the furnace | Part description | Quantity |
| Thermal couple | 1 pc | |
| Stainless steel hook | 1 pc | |
| Tube plug | 4 pcs | |
| quartz tube | 1 pc | |
| vacuum pump | 1 set | |
| sealing flange | 1 set | |
| vacuum gauge | 1 pc | |
| Thermal gloves | 1 pair | |
| Operation manual | 1 pc | |
| Standard size:(Outer diameterX hot zone length) | Dia40x300mm (1.5"x12") | Dia60x450mm (2.5"x18") |
| Dia40x450mm (1.5"x18") | Dia80x300mm (3.0"x12") | |
| Dia60x300mm (2.5"x12") | Dia80x450mm (3.0"x18") | |
| Dia100x450mm (4.0"x18") | ||
| Package: Plastic paper inside, Polyfoam filled, Wooden box outside. | ||
| Payment: L/C T/T, West union, etc. | ||
| Shipping and Delivery: By air, in 15 days after receiving the payment | ||
| Warranty: Our products are warranted to be free from defects in materials or workmanship for one year from the date of purchase. Within this period, Across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the customer for parts, provided that the customer shall be responsible for any transportation cost. This warranty does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs. Replacement will be shipped to you after photo or other evidence are provided and investigated. | ||
Our Services
Packaging & Shipping
Shipping way : By Courier / By sea / By Air /By Train Optional, depend on clients' demad of time and cost.
Shipping terms: Support EXW /FOB/C&F /CIF/ CPT/CIP /DDU /DDP terms...
Company Information
Nanyang Xinyu Furnace Co., Ltd is one professional supplier of high temperature furnace, like lab muffle furnace, atmosphere furnace, Crucible furnace, laboratory tube furnace, dental furnace, vacuum furnace, vertical bell style furnace,CVD tube furnace, multiple heating zone (2/3/5 heating zone) tube furnace, rotary tilting tube furnace, RTP tube furnace and car bottom furnace etc. We have rich experience in the various thermal applications fields, especially on the high temperature lab furnace and heating elements researthing and developping working, which earn us a sound reputation among our product users and clients.
FAQ
What Sell ?
A .What do you sell ?
- Mainly supplying high temperture lab furnaces, such as muffle furnace,tube furnce,vacuum furnace, crucible furnace,porcelalin furnace and other heattreatment.
B .How to choose a furnace?
- Max.Temperature: 1200.C /1400.C/1700.C/1800.C (Constant working temperature is 100.C lower than the max.temperature.)
- Chamber size: 400*300*300mm/300*200*200mm/200*150*150mm/100*100*100mm for muffle furnace or customized
- Diameter 40/60/80/100 mm heating zone length 200/300/400mm for tube furnace . Others can be customized.
- Vauum or protective gas or not.
Why Buy from you ?
- The TOP 3 Furnace manufacturers in China.
- CE Approval
- Factory-- More reasonable price and technical suport compared with trade company.
- Professional after-sales team with 5 members to solve all your query with 7 days 24 hours.
Can I turst you ?
- Alibaba's 9th year verified & gold supplier.
- 24/7 customers service & e-mails help in 2 hours
- Safe purchasing gurantees
