SA-YZ2X80 Transmission Power Line Hydraulic Puller Tensioner For Pulling / Tensioning Conductor



Uses:

Apply to paying off 2 fission ACSR-630 and the following size conductor in mountainous and hilly land area,

Paying off fission ACSR-720 and the following size coductor in flat area, Paying off OPGW,

ADSS or 500kv pulling rope in various area, and replacing lines under all-weather situation.

• Essential parameter


• Maximum Tension(kN):2×90 or 1×180 ,


• Continuous Tension(kN):2×80 or 1×160,


• Maximum speed (km/h):5


• Bull wheel bottom of groove diameter(mm):Φ1850


• Number of grooves:2×6


• Maximum pull-back (kN):2×90 or 1×180


• Maximum pull-back speed(km/h):2×1.7


• Maximum suitable conductor diameter (mm): Φ48.8


• Engine power /speed (kW/rpm):82.5/2500


• Dimensions (mm): 5300×2290×2950


• Weight(kg):10500

Item number		7198	7199	7201	7208	7223	7228
Model		SA-YZ2x70	SA-YZ2x80	SA-YZ2x90	SA-YZ4x50	SA-YQZ40D	SSA-YQZ60
						Puller and Tensioner
Maximum Tension(KN)		2x70/1x140	2x80/1x160	2x90/1x180	4x50/2x100	40	60
Continuous Tension(KN)		2x65/1x130	2x70/1x140	2x80/1x160	4x45/2x90	35	35
Maximum speed(KM/H)		5	5	5	5	5	5
Bottom of groovr diamere(MM)		Φ1700	Φ1700	Φ1700	Φ1600	Φ1200	Φ150
Number of groovr(KN)		2x5	2x5	2x6	4x5	5	6
Number of groovr(KM/H)		2x63/1X126	2x63/1X126	2x90/1X180	4x50/2X100	40	60
maximum speed back(MM)		2x1.6	2x1.6	2x1.7	4x1	5	5
Diameter of Maximum suitable Conductor		Φ45	Φ45	Φ48.8	Φ42.5	Φ32	Φ40
Engine power/speed(KW/RPM)		82.5/2500	82.5/2500	82.5/2500	82.5/2500	851/2500	82.5/2000
Dimensions(M)		5.3×2.3×2.9	5.3×2.3×2.9	5.3×2.3×2.9	5.3×2.3×2.9	4.2×1.8×2.4	5.5×1.9×2.4
Weight(KG)		8500	8500	10500	12000	3600	4800
