Keywords:abrasive sand blasting machine,abrasive sandblasting cabinet,abrasive sandblast cabinet,suction sandblast machine
Model:JL-9080P
Standard dry sand blasting machinery | ||
Model | Outside size (L*W*L mm) | CABIN DIMENSION(L*W*L mm) |
JL6050A | 960*650*1520 | 600*500*520 |
JL6050EA | 960*650*1520 | 600*500*520 |
JL7660A | 1050*810*1580 | 760*600*520 |
JL7660EA | 1050*810*1580 | 760*600*520 |
JL9060A | 1050*950*1580 | 900*600*580 |
JL9060EA | 1050*950*1580 | 900*600*580 |
JL9080A | 1250*950*1580 | 900*800*580 |
JL9080EA | 1250*950*1580 | 900*800*580 |
JL1010A | 1420*1050*1900 | 1000*1000*800 |
JL1212A | 1620*1250*2000 | 1200*1200*800 |
Power supply: | 220V(380V). 50HZ | |
Lighting: | flood light incandescent lamp 220V, 13W | |
Separator motor: | 220V, 50HZ, 0.75KW | |
Compressed air supply: | Dry and clean compressed air with pressure at 2.8-7bar(kg/cm2) and flow of 0.5-1.1m3/min | |
Dust removal: | Bag-type dust collector, powder clearance by compressed air vibration | |
Different between A and EA | there is a Thermostatic heating device in EA : abrasive drying automatically to prevent abrasive from breathing |
More information of sandblasting cabinet as below:
Suction sand blasting cabinet are suitable for surface treatment of all products of metal, plastic and glass ect .removing oxide skin. residues burrs and scratches can be used for decoration light .matte and strengthen management , There are cyclone separation system and dust removal system , separator will separate the abrasive from bust .and dust removal system can deal with and collect the emit useless dust .and can vibrating clean up dust automatically .dust remove effect of good .reduce the cost of abrasive and improve efficiency .and there is no environmental pollution .
Blasting media :White Aluminum Oxide . Brown Aluminum Oxide . Glass Beads .
fast delivery, fast serivce after sale.
Hangzhou Jiyan Machinery Equipment Co.,Ltd(JL Sandblasting company )offer sandblasting machine :sand blast cabinet, pressure sandblasting pot,:mini jewelry sandblaster,vibratory polishing machine,inner pipe wall sandblaster,shot blasting machine,we also offer all kinds of sand blast nozzles,hose coupling,and abrsive media(steel shot,steel grit,corundum,glass beads,aluminium oxide ,ceramic beads) to meet your one-stop purchase.
So far,our sand blasting machine were exported to Australia,New Zealand,England,Ireland,Spain,Greece,Netherlands,Czech Republic,Denmark,Chile,Peru,South Africa,Isreal,Malaysia etc more than 48Countries.
