Good price metal cutting plasma machine 1325 CNC plasma cutter for iron carbon sheet steel plasma machine CNC control



Detailed Product Description

CNC Plasma Machine,Industrial plasma cutting machine,Hypertherm powersupply,high accuracy,smooth cut.



Scope of application:

CNC plasma engraving machine is an automatic and high efficiency engraving equipment. It is widely used in all kinds of metal sheet cutting.





Great feature of our CNC plasma cutter



1 Heavy-duty structure, multi-pillar support, structural distribution of mechanical science

2 High-sensitivity arc voltage (make sure the cuuting performance more accurate and easier to use)

3 STARFIR Control System

4 High-precision square linear rail

5 High Accuracy 1.25 gear distance Helical rack and gear can let the cutting accuracy more higher Higher

6 China most famous government company Chuangwei stepper motor

7 Origional Leadshine driver

8 startcam nesting software

9 20mm thick welding-free integrated treatment of the gantry holder

10 independent control cabinet

11 multifunctional toolbox

12  8G flash disk

13  5 sets of consumables parts (nozzle and electrode )

14China top brand Huayuan 120A plasma

15 all the body  do the anti-rust treatment

16 anti-wear limit switch

17 Cow Eye Wheel feeding system

18 Smoke exhaust system

19 Warranty 2 years

20 Work Area: 1300*2500MM



Specification of metal cutting CNC plasma machine



Model	1530  120A Plasma cutting machine (high configuration
X,Y working area	1500*3000mm
Z working area	150mm
Packing dimension	2280mm*3850mm*1850mm
Lathe bed	Very thick steel structure
Machine Power	8.5kw
Working voltage	380V three phase 60hz
Reposition precision	0.02mm
Processing precision	0.1mm
Maximum cutting speed	12000mm/min
Torch Height control mode	Automatic
Cutting thickness	Max 25mm carbon steel
Plasma power supply	LGK120A China plasma
Control system	STARfire
Motors	Stepper motor
Software	Starcam
Weight	1600KG
Plasma Air Pressure	Max.0.8Mpa
Working Temperature	-10°C-60°C. Relative Humidity, 0-95%.
LCD Display Dimension	7 Inches



Advantage of our CNC plasma cutting  machine



1.We do this line many years, have rich experience and professional knowledge, will let you get the most suitable machine with the right configuration. This ability can let you avoid many mistake and avoid some trouble. Other factory usually lack this experience, and bring some trouble for the real customer.



2.If use the plasma cutting machine to cut the the thick meal, have to use the arc height adjust system, while our height adjust system use the high sensor, one minute can send out 12,000 signal per minute, while other height adjust system usually send out 10000 signal per minute, so our cutting quality more better than other factory and cutting speed a litter faster than the same power plasma source.



3.we equipped the two fan for take the cutting smoke out from the room, front fan will blow to back, the back fan will exhaust the smoke out from the machine and out from the room. This way, will efficiency to let the workshop in the good environment. While other factory does not have this fan or only have one.
