Оцинкованная Строительная платформа ZLP800 для строительства и обслуживания

Working Principle:
The platform is driven by electric hoist and wire rope, running against the building facade while the suspension mechanism was erected on buildings or structures.

Usage and Application:
ZLP series Suspended Platform belongs to high-rise working construction machinery, mainly used to install curtain wall, facade cleaning or other works such as plaster pulp, veneer, paint coatings, oil paint, or cleaning and maintenance, etc., can also be used for large tanks, bridges, dams and other construction operations.

Above all. HUIYANG Platform can increase the efficiency greatly, with simple and flexible operation, easy transfer, convenient and practical, safe and reliable.

1. Working Platform: Steel + Painting; ( Steel+Galvanised or Aluminum Alloy+Painting is available also)
1.1 Working Platform is the workplace at heights for the workers.
1.2 L=7.5m (2.5+2.5+2.5) or (1.5+1.5+2+2.5) or (2+2+2+1.5) W=0.69m; H=1.45m;
1.3 With 4pcs of Bottom Wheel fitted underneath, the platform is easy to move.

2. Suspension Mechanism: Steel Q235 + Painting;
Suspension mechanism is on the top of the building to suspend the platforms through the steel rope.

3. Components:
LTD8.0 Hoist, 1.8kw, 2 sets;
LSD30 Safety Lock, 2 sets;
Electric Cabine: 1 set;
Steel Rope: 4pcs, 100m/pcs; D=8.6mm;
Electric Cable: 1pcs, 100m/pcs, Rubber, 3x2.5+2x1.5mm sq;
Safety Rope: 1pcs; 100m/pcs;
Counterweight (Optional): 40pcs, 25kg/pcs.

Pre-Sales Service

* Factory Show.
* Consulting Support
* Fast Quotation and PI Feedback
* Deposit
* Sample Testing

After-Sales Service

* Video Training: how to instal the machine.
* Engineer Online Service.
* Email Instruction.
All products purchased from our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free.

High quality

Passed the ISO9001:2008 quality system authentication and  no one accident happend in our past history.

Ningjin Huiyang Construction Equipment Co., Ltd, established in 2005,located at Dezhou City, is a professional and accurate technique corporation who is professional in the R&D production and sale of suspended access equipment on high operation, and the accessories such as Safety Lock, Hoists, Electric Control Cabinet, Fasten Wire Ropes, and etc.

Now Huiyang becomes the production base and research centre of exporting suspended access equipment in China. The quality of Huiyang Suspended Platform is in the first-class in China and our products have been exported to more than 20 countries, which can be comparable with European famous suspended platforms.

Huiyang Suspended Platform is one of the largest enterprises engaged in well-known suspended platform in China, and annual production capacity is up to 8000 sets. In China, Huiyang suspended platform owns the most complete categories, specifications, and applications compared with same industry. They have been used in every aerial area with the main models ZLP500, ZLP630, ZLP800 and ZLP1000. The Voltage and Frequency could be up to different countries' standard, such as single-phase 220V, triplicate-phase 2200V, 380V etc.

No matter what structure needs, everything is easier with Huiyang.
