Product Description
RobotLinking HC-SR501 Pyroelectric Infrared PIR Motion IR Sensor Body Detector Modules Raspberry Pi(Green)
We are professional manufacturer and exporter that is mainly engaged in research and development, production and sales of printers, raspberry pi and other electronic components. We strive to ensure that all of our customers are completely satisfied, and it is our hope that you truly are. Feel free to comment on how the product is working for you. Thank millions!
Specifications:
Dimension: 1.26*0.94in
DC voltage: 4.5-20V
Quiescent Current: <50uA
Level output: High 3.3 V / Low 0V
Trigger mode: L unrepeatable trigger / H repeat trigger (default trigger repeat)
Delay time: 0.5-200S (adjustable) range can be made zero seconds - several minutes
Block time: 2.5S (default) range of a few tenths can be made - tens of seconds
PCB Dimensions: 32mm * 24mm
Induction angle:<100 degree cone angle
Operating temperature: -15- + 70 degrees
Induction lens size: Diameter: 23mm (default)
Dimension: 1.26*0.94in
DC voltage: 4.5-20V
Quiescent Current: <50uA
Level output: High 3.3 V / Low 0V
Trigger mode: L unrepeatable trigger / H repeat trigger (default trigger repeat)
Delay time: 0.5-200S (adjustable) range can be made zero seconds - several minutes
Block time: 2.5S (default) range of a few tenths can be made - tens of seconds
PCB Dimensions: 32mm * 24mm
Induction angle:<100 degree cone angle
Operating temperature: -15- + 70 degrees
Induction lens size: Diameter: 23mm (default)
Applications:
Security Products,The human body sensors toys,The human body sensor lighting industrial automation and control, etc.It can automatically and quickly open various types of incandescent, fluorescent lamps, buzzer, automatic doors, electric fans,automatic washing machine and dryer Machines and other devices.
Especially suitable for enterprises, hotels, shopping malls, warehouses and family aisles, corridors and other sensitive Sense of region, or for the security zone automatic lighting, lighting and alarm systems
Security Products,The human body sensors toys,The human body sensor lighting industrial automation and control, etc.It can automatically and quickly open various types of incandescent, fluorescent lamps, buzzer, automatic doors, electric fans,automatic washing machine and dryer Machines and other devices.
Especially suitable for enterprises, hotels, shopping malls, warehouses and family aisles, corridors and other sensitive Sense of region, or for the security zone automatic lighting, lighting and alarm systems
If you have another question, Please contact us.
We will actively understand the ideas of the customers, and make improvements to our products, and strive to satisfy more customers.
We will actively understand the ideas of the customers, and make improvements to our products, and strive to satisfy more customers.
Packing list:
1 X RobotLinking HC-SR501 Pyroelectric Infrared PIR Motion IR Sensor Body Detector Modules Raspberry Pi(Green)
