45 port 2 position 4F210-08 Pneumatic 5/2 Way 1/4'' Direct Acting Air Foot Valve Airtac Pneumatic Foot Pedal Valve
Product Description
Ordering Code
4F210 - 08 L
Series Port size Noted
4F210:5/2 Way Foot pedal valve 08: 1/4'' Blank: without lock
L: with lock
G: with guard
LG: with lock & guard
Inner structure and material of major parts:
| NO | Item | NO | Item | NO | Item |
| 1 | Pin | 8 | O-ring | 15 | Pedal spring |
| 2 | Screw | 9 | Front cover | 16 | Washer |
| 3 | Spring | 10 | Piston | 17 | Screw |
| 4 | E clip | 11 | Bottom cover | 18 | Base pad |
| 5 | Pedal | 12 | C clip | 19 | Screw |
| 6 | Spool | 13 | Silencer | 20 | Base pad |
| 7 | O-ring | 14 | Base |
Specifications
| Model | 4F210-08 | 4F210-08L | 4F210-08G | 4F210-08LG |
| Fluid | Air( to be filtered bu 40 µ m filter element) | |||
| Acting | Acting type controlled by foot | |||
| Port size | 1/4'' | |||
| Pressure range | 0~1.0MPa(0~145psi) | |||
| Proof pressure | 1.5MPa(215psi) | |||
| Temperature °C | -20~70℃ | |||
| Material of body | Aluminum Alloy | |||
| Lubrication | Not required | |||
Product Details
Main Product
Company Information
Our Service
FAQ
Q: What is your MOQ?
A: 5pcs for MOQ.
Q: What is your packing?
A: Each Solenoid Valve by one box packing.
Q: What is your quality?
A: Sample will tell you what you want.
Q: What is your warranty?
A: One year under normally used.
Q: Can you do OEM?
A: Yes, we can.
