Лазерная гравировальная машина 3D для стеклянных

Описание и отзывы

Характеристики

Inside 3D  Laser Engraved Crystal

Features:

1.It is specialized for fine sub-surface engraving.



2.It adopts scanner and worktable linkage working mode.



3.Its working efficiency is 3KHZ (max. 3000 points/sec) that is much higher than common model.



4.The software supports DXF,ASC,BMP format and so on.



5.Key parts of the apparatus mainly come from Germany and the USA. It is more reasonable and steady for long-term production.



6.Suitable for individual production and batch fast process.



7.One machine could be satisfied with capacity for both storefronts network distribution and electric-business distribution.



Parameters:



Description	Parameter :SW-1010
Type	laser inside engraving machine
Laser Medium	Diode End Pumped
Laser Wavelength	532nm
Laser Power	2.7W/3kHz
Laser Power Stability	±3%(Continuously Running 24hrs)
Max.Engraving Area	110*110*80mm
Laser Beam Quality	M2<5
Max.Engraving Speed	3000 points/sec
Positioning Accuracy	0.005mm
Focus Diameter	0.02mm
Software	Professional Software for Crystal Engraving
Adjust Q-Frequency	3000kHz
Graphic Formats	DXF, ASC, BMP etc
Environmental Temperature Required	15~30°C
Cooling Way	Forced-air Cooling
Working Power	220V/50~60Hz
Power Consumption	3kW
Overall Weight	80kg
Dimension	890*580*695mm
Package	Wooden Box
Optional Parts	Software/3D Camera/Crystals



After service and Warranty:



After sales service	1.24 hour technical support by email and calling
	2. English manual and CD vedio for machine using and maintaining.
	3.Whole machine Warranty 1 Year.
Quality Control	1.Strect control machine assembly each link,ensure the machine clean and beautiful.
	2.48 hours continuous work before the machine leave the factory, ensure high quality of the machine.



Samples:
