Product Description


U02





Specification











































































Model U02
Product Name Oil level Ultrasonic module
Highlight Non contacted measuring.
Metal case and Waterproof design, IP68 protection grade.
Wide voltage power input supported..
Strong anti-interference, anti-static abilities
Data output stable and reliable
Long measurement range, high accuracy
Automatic output mode, not occupy hardware resources
Controlled output mode, low power consumption
Operating Voltage DC 12-48v
Operating Current <25 mA
Blind Area Distance 5 cm
Measuring Range 5-100cm
Accuracy <5 mm
Resolution <1 mm
Measuring Angle 2-4°
Container thickness 0.6-5mm
Output Method RS232/RS485/TTL-UART ports, auto/modbus/capacitive modes
Frequency 40 KHz
Temperature Compensation Yes (PWM no compensation)




Applications













































liquid level measurement, loop control, diameter sensing and strip speed control
Liquid Level Measurement in Small BottlesLoop controlDiameter Sensing and Strip Speed Control
Contour Recognition, Quality Control, Vehicle Sensing and Positioning
Contour RecognitionQuality ControlVehicle Sensing and Positioning
Wire or Rope Breakage Monitoring, Stack height sensing, Bottle Counting
Wire or Rope Breakage MonitoringStack height sensingBottle Counting
breakage sensing, people sensing, human body height measurement
Breakage SensingPeople Sensing, Human body Height measurementLiquid Level Measurement in Large Vessels(Tanks, Silos)
flat object sensing or detection, anti-collision, proximity alarm, height sensing
Flat Object sensing or detectionAnti-Collision, Proximity AlarmHeight Sensing




Certificates


certificates-2





FAQ


1. Are you a manufacturer or trading company?


DYP is a manufacturer, our factory approved by ISO9001:2008, ISO14001:2004 standard.





2. Does your products can be ODM or OEM?


Yes, we provide ODM/OEM services, we can customize the product according to your requirement, after estimated by our R&D team, We can build the product you need on the basis of existing products, or build a brand new product.





3. What's warranty of your product?


We provide 1 year warranty, any defective items, please send back to us, we will repair/replace for you.





4. What is the terms of payment?


for the sample order, we suggest place order on alibaba directly. for the large order, we accept TT or LC.





5. Do you provide technical support?


Yes, we have our own R&D department, we can provide you technical support at any time. you can call us or write email to us.





6. How to choose the right ultrasonic sensor?


First of all, clarify the installation conditions:


   a. Medium to be measured;


   b. Installation location;


   c. Measurement range;


   d. Measurement accuracy;


   e. Sensor resolution;


   f. potential interference;


   g. Whether vessels has pressure.


Select the corresponding series of products according to the medium, and then select the product suitable for the conditions according to the Range, Accuracy, Angle etc parameters. If there is no suitable one, we also provide OEM/ODM services, please contact us.
