1. It equipped with automatic constant temperature controlling device.
2. The cutting machine adopts speed regulating motor, which can cut the material according to the feeding speed of the extruder.
3. With such features, with such as high output low noise, stable performance and easy operation, it is a more ideal waste plastic material regenerative pelletizer.
4. Applicable raw material: HDPE/LDPE, PP materials
5. Power supply: 380v, 50Hz 3 Phase
6. Material of screw and barrel: Alloyed high-quality steel 38CrMoAlA with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment
7. Gear box: Hard Surface Gear
8. Automatic temperature controlling system
9. Including water-cooling device made of stainless steel
10. Including granule cutter
11. Force Feeding Unit is optional
Model | SJY-100 | SJY-110 | SJY-120 | SJY-130 | SJY-140 | SJY-160 |
Production | 70-90kg/h | 90-120kg/h | 100-130kg/h | 130-180kg/h | 150-200kg/h | 200-250kg/h |
Main Extruder Screw Size | 97mm | 107mm | 117mm | 127mm | 137mm | 157mm |
Second Extruder Screw Size | 95mm | 97mm | 105mm | 115mm | 115mm | 135mm |
Hydraulic Screen Changer | Yes | Yes | Yes | Yes | Yes | Yes |
Force Feeder | Yes | Yes | Yes | Yes | Yes | Yes |
Main Motor Size | 22kw | 30kw | 37kw | 45kw | 55kw | 75kw |
Second Motor Size | 11kw | 11kw | 15kw | 15kw | 18.5kw | 30kw |
Main Extruder LD | 20:1 | 20:1 | 20:1 | 20:1 | 20:1 | 20:1 |
Second Extruder LD | 11:1 | 11:1 | 11:1 | 11:1 | 11:1 | 11:1 |
Main Motor Inverter | 22kw | 30kw | 37kw | 45kw | 55kw | 75kw |
No. | Spare parts name | Quantity |
1 | Temperature meter | 1set |
2 | Electric Sensor | 2 pc |
3 | Heating ring | 3 pc |
4 | Tool box | 1set |
5 | English manual | 1pc |
Q1: Are you a factory or trading company
A1: We are a factory, we can guarantee our price is first-hand, very cheap and competitive.
Q2: How does your factory do regarding quality control?
A2: All the products will be 100% checked before the shipment.
Q3: When can I get the price?
A3:Usually we quote within 24 hours after we get your inquiry.
Q4: How could I get a sample?
A4: if you can not buy our product in your local area, we will ship a sample to you.You will be charged a sample price plus all related shipping costs.Express delivery charge depends on the quantity of the samples.
Q5: What is the price of shipping?
A5: Depending upon the port of delivery, prices varies.
