Минеральный сепаратор
Полная хромированная установка для мытья Гравитационный спиральный желоб концентратор машина разделения хромитовой руды энергичный и Горный Спиральный

Полная хромированная установка для мытья Гравитационный спиральный желоб концентратор машина разделения хромитовой руды энергичный и Горный Спиральный

Категории: Минеральный сепаратор >>>
Поставщик: Jiangxi,Hengchang,Mining,Machinery,Manufacturing,Co.,Ltd.

Цена:1 000,00 $ - 1 250,00 $*

Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики

Complete Chrome Wash Plant Gravity Spiral Chute Concentrator Chromite Ore Separation Machine Chrome Ore Processing Plant

Hengchang machinery spiral chute separator can be used for many minerals separating, such as gold, copper, tungsten, tin, tantalum, coltan, chrome, zinc ore and some other minerals. When you find us, you find one best mining machinery manufacturer.

Chrome Ore Processing Plant Introduction:
Spiral chute is also called spiral chute or spiral chute separator, is the best equipment in mining and ore dressing industries, which is often applied to sort materials with size 0.3 - 0.02 mm, such as ilmenite, chromite, pyrite, zircon, rutile, monazite, phosphate, tungsten ore, tin, tantalum, niobium ore and other non-ferrous metals, precious metals and non-metallic minerals.
It can easily adopt to different raw material size, density, ore grade and feed volume. Spiral chute is suitable for treatment of 0.6-0.03mm lode and placer, but high mud content is bad for separation. At present, spiral chute has been widely used in the treatment of iron ore, tungsten, tin ore, niobium tantalum ore, coastal and riverside placer and gold ore.

Chrome Ore Processing Plant Working Principle:

Spiral chute is working under the the force of water flow, gravity, inertial centrifuge and friction. Slurry is pumped to the top of the spiral , and it enters a feed distributor that evenly distributes the feed to each spiral concentrator. The design and shape of the spiral make it work, when combined with gravitational acceleration. As the slurry travels the spiraling path down the spiral, mineral grains settle and start sorting according to size, density and to a lesser extend shape. Low density particles are carried with the bulk of the water towards the outside of the spiral , while particles with the greatest density migrate towards the inside of the spiral.

Fiber Reinforce Plastic Spirals

Diffluent Box

Normal Type Spiral

Riffle Type Spiral

BLL-400 Spiral Chute

BLL-600 Spiral Chute

BLL-900 Spiral Chute

BLL-1200 Spiral Chute

BLL-1500 Spiral Chute

PVC Spiral Chute

Chrome Ore Processing Plant Applications:

The spiral chute is a gravity equipment. With the water, action of gravity friction force, minerals would be separated by its gravity difference. Then we could get heavy, middling and light products.It is made of the fiberglass lined with wear-resistant polyurethane and corundum cover; the advantages are light, moisture proof, anti-rust, wear proof,anti corrosion and no noise, properly suitable for the different feeding particle sizes and grades. It is the domestic advanced level, the new high effective equipment.

Model	BLL-1500	BLL-1200	BLL-900	BLL-600	BLL-400
Outside Diameter (mm)	1500	1200	900	600	400
Screw Pitch (mm)	900, 675	900, 720, 540	675, 540, 405	450, 360, 270	240, 180
Pitch Diameter Ratio	0.48, 0.36	0.75, 0.6, 0.45	0.75, 0.6, 0.45	0.75, 0.6, 0.45	0.6, 0.45
Lateral slope (degree)	9°	9°	9°	9°	9°
Max. Screw Numbers	4	4	4	2	2
Feed Size (mm)	0.8 ~0.037	0.3~0.03	0.3 ~0.03	0.2~0.02	0.2 ~0.02
Feed Density (%)	30 ~55	25 ~55	25 ~55	25 ~55	25 ~55
Capacity (t/h)	6~8	4~6	2~3	0.8~1.2	0.15~0.2
Length (mm)	1600	1360	1060	700	460
Width (mm)	1600	1360	1060	700	460
Height (mm)	5300	5230	4000	2600	1500
Weight (kg)	850/800	700/650/600	450/400/350	150/120/100	50
