Product Description
Hot Selling YTO 1.5Ton Diesel Forklift CPC15 with High Quality
A larger underground clearance of the chassis may overcome many kinds of complex terrain working.
The off-road mobility is enhanced through by driver wheels with the MPT multi-function tires, wide base and cross-country tread pattern.
Uses the integral-type combination instruments, the fuse box places in left side of the steering wheel, which advantage for the replacement, also installed with a cigar lighter.
A yellow caution light .Outlay air filter and inside air filter increase the purification performance greatly
Apoting Xinchang A495 Engine ensure the powerful performance
Adjustable damping seat with safety belt
Basic parameter | Model | Unit | CPC15 | |||
Power type |
| Diesel | ||||
Rated capacity | kg | 1500 | ||||
Load center | mm | 500 | ||||
Lift height | mm | 3000 | ||||
Mast tilt angle (forward/backward) | Deg | 6/12 | ||||
Wheel-base | mm | 1600 | ||||
Tread(front/rear) | mm | 960/970 | ||||
Performance parameter | Travel brake |
| Hydraulic-Foot pedal | |||
Parking brake |
| Mechanical-Hand level | ||||
Lift speed(with/without load) | mm/s | 550/600 | ||||
Lower speed (with/without load) | mm/s | with load<600,without load>300 | ||||
Travel speed (with/without load) | km/h | 14/15 | ||||
Max. gradeability (with load) | % | 20 | ||||
Max. Towing (with/without load) | kN | 16/12 | ||||
Weight Distribution with load(front/rear) |
| 4650/890 | ||||
Weight Distribution without load(front/rear) |
| 1360/2180 | ||||
Power, transmission and others | Engine | Model |
| C240 | ||
Manufacturer |
|
| ||||
Rated power | kw | 34.5/2500 | ||||
Max. rotation | Nm/rpm | 134/1800 | ||||
Displacement | L | 2.369 | ||||
Battery | Voltage | V | 12 | |||
Capacity | Ah | 100 | ||||
Gearbox | Transmission type |
| Hydraulic | |||
Gears speed (front/rear) |
| Ⅰ/Ⅰ | ||||
Tire | type |
| Pneumatic Tires | |||
Model | Front |
| 7.00-12-12PR | |||
Rear |
| 6.00-9-10PR | ||||
Others | Self weight | kg | 3540 | |||
Free lift height | mm | 160 | ||||
Fork | T×W×L | mm | 40×100×920 | |||
Overall dimensions | Overall length (without forks) | mm | 2600 | |||
Overall width | mm | 1150 | ||||
Overall height | Extended height(mast) | mm | 4030 | |||
Lower height(mast) | mm | 2000 | ||||
Overhead guard | mm | 2120 | ||||
Min. turning radius | mm | 2170 | ||||
Min. under ground clearance | Under mast | mm | 105 | |||
Center of wheel-base | mm | 150 | ||||
