Токарный станок Tornos New Китай высокое качество по низкой

Specification

Model

CQ6280

Swing over bed

800mm (31-1/2’‘)

Swing over cross slide

570mm (22-7/16”)

Swing in gap diameter

1035mm (40-3/4”)

Distance between centers

1500mm(60”) 2000mm(80”) 3000mm(120”)

Valid length of gap

250mm(10”)

Width of bed

400mm(15-13/16”)

Spindle nose

D1-8

Spindle bore

105mm(4-1/8”)

Taper of spindle bore

Φ 113(1:20)

Range of spindle speed

25~1600 r/min

Compound rest travel

230mm(9-1/8”)

Cross slide travel

420mm(16-17/32”)

Max. section of tool

25x25mm(1” x1”)

Lead screw thread

12mm or 2T.P.I

Longitudinal feeds range

0.044~1.48mm/rev

(0.00165”~0.0550”/rev)

Cross feeds range

0.022~0.74mm/rev

(0.00083”~0.02774”/rev)

Threads metric pitches

54 kinds, 0.45~120mm

Threads imperial pitches

54kinds, 7/16~80 T.P.I.

Threads diametral pitches

42kinds, 7/8~160DP

Threads module pitches

46 kinds, 0.25 ~ 60MP

Quill diameter

90mm(3-1/2”)

Quill travel

235mm(9-1/4”)

Quill taper

No.5 Morse

Main motor power

7.5kW(10HP)3PH

Coolant pump power

0.1kW(1/8HP) 3PH

Overall

dimension(Lx WxH)

321x123x167cm

371x123 x167cm

471x123 x167cm

Packing size(LxWxH)

324x114x191cm

374x114x191cm

474x114x191cm

Net weight

3175kg

3455kg

3820kg

Gross weight

3695kg

4005kg

4495kg
