Operation type | Pallet type | Lifting type |
Model No. | CBD20/25/30 | CQD15A-40 |
Power type | Full Electric | Full Electric |
Load capacity | 2/2.5/3 T | 1.5/2.0 T |
Load Center | 600mm | 600mm |
Fork Min height from the Ground | 85mm | 90mm |
Fork size | 1200*175 mm | 1070*100*35mm |
Max.Lifting height | 200mm | 3000mm |
Battery capacity | 24V/210AH | 24V/150AH |
Lifting speed | / | 110m/s |
Overall height | 1400mm | 2150mm |
Driving motor | 1.5KW | 1.2KW |
Lifting motor | 0.8KW | 2.2KW |
Max.walking speed | 5km/h | 5km/h |
