500L жидкие химические добавки для смесительное оборудование с уход за кожей лица крем-гель смешивания машина жидкое мыло
- Категории: Mixing Equipment >>>
- Поставщик: Zhejiang,Hengdong,Stainless,Steel,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
Wholesale yogurt cream mayonnaise mixing machine/ liquid olive oil homogenizer mixer tank/ cosmetic gel mixing machine
Specification
Material: SS304 / 316L;
Capacity: 50-5000L (customized is accepted);
Configuration with agitator and/or homogenizer;
Jacket: single layer, double jacket, three-layer
Thickness: 2mm, 3mm, 4mm, 5mm, 6mm, 8mm etc. (design according to pressure);
Head: open cover, seal with manhole/handhole etc.;
Shape: cylinder or cone, conical/flat/elliptical bottom with discharge.
Heat Method: steam, electricity, hot water or oil circulated.
Structure
The equipment is a liquid storage containers, composed of reducer, stirring paddle and the material valve, disc thermometer and other components.
Single Layer
The inner layer: adapts stainless steel plate SS304 or 316L material, and the surface mirror polishing.
Double Jacket
The jacket: made of SS304 steel, spiral jacket device, cold water from the bottom up without pressure, to achieve the purpose of the best heating and cooling.
The jacket: made of SS304 steel, spiral jacket device, cold water from the bottom up without pressure, to achieve the purpose of the best heating and cooling.
Three Layers
The external insulation layer: the environmental polyurethane foam casting/ perlite particles, maintaining the temperature difference with the outside, to the effect of insulation.
The external insulation layer: the environmental polyurethane foam casting/ perlite particles, maintaining the temperature difference with the outside, to the effect of insulation.
Reducer
Reducer output shaft connected with the stirring paddle, the use of looper connection, easy disassemble and cleaning.
Reducer output shaft connected with the stirring paddle, the use of looper connection, easy disassemble and cleaning.
Additional Devices
Sterile respirator, sterile sampling port, manhole/ cover, inlet and outlet, thermometer, CIP cleaning spray balls, Liquid level gauge, ladder, (Other special customized requirements from customers are acceptable.)
Sterile respirator, sterile sampling port, manhole/ cover, inlet and outlet, thermometer, CIP cleaning spray balls, Liquid level gauge, ladder, (Other special customized requirements from customers are acceptable.)
Application
It is widely used in dairy industry, food industry, pharmacy, chemical industry, beverage and other industrial sectors, as heating, cooling, heat preservation, anti-corrosive, anti-corrosive, strong production capacity, Cooling, insulation, sterilization treatment or storage of slurry must be stainless steel mixing tanks, especially for pasteurization of milk and
insulation, ice cream production line is the necessary equipment. All joints and inside is mirror finished without any dead angle and cleaned easily. It consists of inner vessel, jacket and insulation with the configurations of agitator, CIP hole, manhole, sight glass, thermometer etc.
insulation, ice cream production line is the necessary equipment. All joints and inside is mirror finished without any dead angle and cleaned easily. It consists of inner vessel, jacket and insulation with the configurations of agitator, CIP hole, manhole, sight glass, thermometer etc.
Parameters
Model | Power (KW) | Speed (r/min) | Dimension of Tank (mm） | Insulation (mm) |
HD-1000 | 7.5 | 2800 | 1060x1220 | 50 |
HD-2000 | 11 | 2800 | 1340x1500 | 50 |
HD-3000 | 15 | 2800 | 1410x2000 | 50 |
HD-4000 | 18.5 | 2800 | 1620x2000 | 50 |
HD-5000 | 22 | 2800 | 1810x2000 | 50 |
Product Display
Related Products
Company Profile
Guangzhou HUNDOM Machinery Equipment Technology Co., Ltd is a high-tech enterprise integrating R&D, manufacture and sales, with more than 18 years of mechanical manufacturing experience. Main production: Stainless steel mixing tank, in-line high shear mixer, transfer pumps, colloid mill etc. HUNDOM has mature technology, professional engineer team and high quality products to meet various requirements in the field of food, pharmaceutical and household chemical industries. We provide a full range of effective solutions and after-sales service for customers, machines are hot sell all over the world. The mature technology and rigorous attitude are the guarantee of HUNDOM Technology’s product quality.
FAQ
1. About Delivery term
Q: What's the delivery term for doing business with you?
A: EXW/FOB/CIF/DDU… it depends on preference of clients.
2. About Lead time
Q: What's the leading time after placing order?
A: After getting your confirmation, mixing tank about 25 days, pump 15 days, colloid mill 10 days. However, it depends on production schedule is in slack or peak season, and the complication of machines.
3. About Payment time
Q: What's the payment term?
A: T/T 40% as down payment, 60% balance payment before delivery.
4. About Quality
Q: How do you control your quality?
A: All machines before delivery will be tested and send video for customer, if no problem then arrange balance payment. Meanwhile,CE is available for customers' needs.
5. About Packing
Q: How do you pack the machines?
A: Standard export wooden case, to avoid damage during delivery.
6. About Customized
Q: Can you produce according to the samples?
A: Yes,we can produce by your samples or technical drawings.
Q: What's the delivery term for doing business with you?
A: EXW/FOB/CIF/DDU… it depends on preference of clients.
2. About Lead time
Q: What's the leading time after placing order?
A: After getting your confirmation, mixing tank about 25 days, pump 15 days, colloid mill 10 days. However, it depends on production schedule is in slack or peak season, and the complication of machines.
3. About Payment time
Q: What's the payment term?
A: T/T 40% as down payment, 60% balance payment before delivery.
4. About Quality
Q: How do you control your quality?
A: All machines before delivery will be tested and send video for customer, if no problem then arrange balance payment. Meanwhile,CE is available for customers' needs.
5. About Packing
Q: How do you pack the machines?
A: Standard export wooden case, to avoid damage during delivery.
6. About Customized
Q: Can you produce according to the samples?
A: Yes,we can produce by your samples or technical drawings.
