Products Description
Introduction of EF450 Electric Forklift 4 Wheel Mini Electric Forklifts Trucks Price
Standard configuration: rated lifting weight,equipped with two-stage 3m mast, standlard1220mm fork, imported double drive motor,imported electric control, imported hydraulic parts, imported gearbox, fingertip control, equipped with 700Ah power battery, intelligent charger, four Wheel solid tires, lifting speed regulation, high-end safety seats
Product Paramenters
Parameter of EF450 Electric Forklift 4 Wheel Mini Electric Forklifts Trucks Price
Characteristic | Rated lifting weight | kg | 5000 | ||
Load center distance | mm | 500 | |||
Overhang | mm | 409 | |||
Front overhang | mm | 565 | |||
Wheelbase | mm | 2000 | |||
total weight (No load With battery) | kg | 800 | |||
Size | Total length (To vertical surface of fork) | mm | 2975 | ||
Total width | mm | 1496 | |||
Height of overhead guard | mm | 2300 | |||
Standard mast height that does not rise | mm | 2300 | |||
Standard mast Maximum stretch height | mm | 4110 | |||
Maximum fork height (Rated lifting weight) | mm | 3000 | |||
Standard mast inclination( Leanforward/Reclining) | deg | 6/6 | |||
Ground clearance of frame | mm | 140 | |||
Standard mast Free lifting height | mm | 170 | |||
Turning radius (Smallest outside) | mm | 150 | |||
Mlinimum theoretical width of right-anglechannel | mm | 2650 | |||
Minimum theoretical width of right-anglestacking channel | mm | 2650 | |||
Fork pitch range | mm | 4750 | |||
The smallest x The largest | mm | 300X1350 | |||
Performance | Maximum travel speed (No load) | Km/h | 18/16 | ||
Lifting speed (fully loaded/No load) | Mm/s | 400/500 | |||
speed of decent(fully loaded/No load) | Mm/s | 450/450 | |||
Largest traction(fully loaded/No load) | N | 25720\\23950 | |||
Maximum grade (fully loaded) | % | 20 | |||
Tires | Front wheel | 28x12.5-15 | |||
Rear whee1 | 21x8-9 | ||||
Power system | battery(1ithium optiona1) | Voltage | V | 80 | |
Capacitance | ah | 400-830 | |||
Rated power of wa1king motor | Kw/rpm | 2x12 | |||
Rated power of 1ifting motor | Kw/rpm | 25.5 | |||
Control1er form | Ac | ||||
Details Images
Photos of EF450 Electric Forklift 4 Wheel Mini Electric Forklifts Trucks Price
