1 5 тонны 2 3 Тонны Электрический Аккумуляторный вилочный
- Категории: Forklifts >>>
- Поставщик: Jinan,Shine,International,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
1 | Features | Operating Type | - | Sit-on | |
2 | Rated load | kg | 2000 | ||
3 | Load center | mm | 600 | ||
4 | Weight(in battery) | kg | 3450 | ||
5 | Size | LxWxH | mm | 2565x1290x2470 | |
6 | Fork size | LxWxT | mm | 1220x122x40 | |
7 | Wheel Base | mm | 1510 | ||
8 | Lifting height | mm | 5600 | ||
10 | Free lifting height | mm | 1570 | ||
11 | Door frame angle | 1/3 | |||
12 | Reach distance | mm | 600 | ||
14 | Support Arm Medial Width | mm | 920 | ||
15 | To The Length Of The Support Arm | mm | 1920 | ||
17 | Min. Ground Clearance | mm | 90 | ||
18 | Motor | Power of driving motor | kw | 6.4 | |
19 | Power of lifting motor | kw | 11.5 | ||
20 | Battery voltage/Rated capapcity | V/Ah | 48/500 | ||
21 | Drive control mode | MOSFET | |||
22 | Weight(battery) | kg | 890 | ||
23 | Working Performance | Right Angle Stacking Aisle Width Pallet Size: 800*1200 The Edge of The Size | mm | 2380 | |
24 | Turning Radius | mm | 1725 | ||
25 | Travel Speed Full Load/No Load | kw/h | mm | 9.5/10.5 | |
26 | Lifting Speed Full Load /No Load | mm/ | kg | 260/360 | |
27 | Descent Speed Full Load/No Load | mm/ | V/Ah | 500/400 | |
28 | Grade Ability Full Load/No Load | % | kw | 10/15 |
Detailed Images
2 driving motor+ 1 steering motor
Double Curtis controller
Chinese best brand battery
Mounted right operation handle
LED rainproof Dispaly screen
Full LED Light
Toyota comfortable seat
Electric Steering
Camera
Optional Attachments
SNSC forklift can install different attachments to help your work, like paper roll clamp, side shifter, full free container mast,
bale clamp, drum clamp, block clamp, fork positioner, tyre clamp, rotators, carton clamp, cabin, etc.
bale clamp, drum clamp, block clamp, fork positioner, tyre clamp, rotators, carton clamp, cabin, etc.
Quality Control
SNSC Forklifts have strict quality control system. Although strict quality control has been carried out during the production process, to ensure our customers can receive high performance forklifts, all of our forklifts will be tested again before delivery.
Our quality inspection is divided into indoor inspection and outdoor inspection. Indoor testing includes braking performance, the inclination angle of mast, detection of chassis oil leakage, counterweight, etc. Outdoor testing includes loading, lifting, tilting, turning, climbing, etc.
Tilt angle test
Wheel hug test
Brake Line Test
Climbing test
Lifting Test
Turning Test
Package and Delivery
3 wheel electric 1.6ton battery operated forklift with cheap price Shipping with Tool Box, Forklift truck Catalog, Gloves and Forklift truck Operation and Maintenance Manuals, Fork Sleeves and Spare Parts together.
Packaging&Shipping 1*20'GP - 4 Units, 1*40'GP - 6 Units
Packaging&Shipping 1*20'GP - 4 Units, 1*40'GP - 6 Units
Successful Cases
SNSC --"Beyond your needs!"
SNSC as a professional manufacturer of industrial vehicles, offer your various solutions for moving and stocking materials, such as diesel forklifts from 1.5t to 10t, electric forklifts from 1t to 3.5t, LPG gasoline electric stacker, warehouse trucks.
1.6ton Three wheel electric forklift to Argentina
1.8on Three wheel electric forklift to Algeria
2ton Three wheel electric forklift to Austrila
1.6ton Three wheel electric forklift to Turnisa
2ton Four wheel electric forklift to Canada
1.6Ton Three wheel electric forklift to Turnisato Bangaladesh
Our Factory
We are top 3 in Chinese forklift manufactures and top 20 in the world,over 300 employees,10,000 units forklift truck production capacity per year,5000 sets export volume.
our R&D research is in Britain, and we invested 600 million in forklift factory, use advanced equipments, eg: welding robot and others to realize over 95% automatic production line.
our R&D research is in Britain, and we invested 600 million in forklift factory, use advanced equipments, eg: welding robot and others to realize over 95% automatic production line.
Material Preparation Workshop
Structure Workshop
Painting Workshop
Assembly Workshop
