automatic bobbin change winder fdy yarn bobbin winder machine:



The advanced heat treat ment , alloy spraying equipment ,vacuum hardening furnace and cementite oven and chrome

plating workshop insure products have higher quality .





High speed winder for FDY running 1200-2800m/min . BCF winder running speed 1000-2500m/min .

for polyester yarn running speed 2500-3500m/min .



automatic bobbin change winder fdy yarn bobbin winder machine

Automatic wind doffing for  POY FDY  BCF Spinning Machine



Winder with tail yarn device . more convenient for next process .





 For bobbin size  ¢110*¢125*200mm(100,120mm,250mm ) , most popular size is 230mm lenght with loading capacity of 13kgs .

or bobbin size ¢110*¢125*150mm

 automatic bobbin change winder fdy yarn bobbin winder machine











Electric cable design 12 meters length , its convenient for put the electric cabinet every where far from the winder machine .

POY BCF CF FDY spinning machine for take up winder









Electric cable design 12 meters length , its convenient for put the electric cabinet every where far from automatic doffing

12 ends fdy pp multifilament yarn winder machine .



automatic bobbin change winder fdy yarn bobbin winder machine

POY BCF CF FDY spinning machine for take up winder







 4 ends winder and 6 ends winder been running 10 years ,still very good performance .



 Automatic wind doffing for  POY FDY  BCF Spinning Machine

6 ends winder side view . easy operate and high high machining accuracy







Electric parts adopt YASKAWA , SIEMENS,MITSUBISHI brand . its easy for customer source from local .





automatic bobbin change winder fdy yarn bobbin winder machine parameter:



winder model	speed (m/min)	tube size	Applications	ends number	chuck length(mm)	stroke length(mm)	volume(dm)
JM435/6	1200-2800	75*89*100	PP PET PA6	6	600	73	7.0
JM435/4	1200-2800	75*89*150	PP PET PA6	4	600	120	11.5
JM435/3	1200-2800	75*89*200	PP PET PA6	3	600	170	16.3
JM435/2	1200-2800	75*89*300	PP PET PA6	2	600	250	23.9



    TAIAN JIAMEI MACHINERY TECHNOLOGY CO.LTD

We are professional fdy yarn & components manufacturer . winder is a main parts of spinning machine .

Our winder products have very good performance and durable lifetime .with more than 15 years of export experience ,

our winder products getting more and more mature and best feedback from customer .

engaged in filament extrusion machinery for 30 years ,workshop with area 8000 square meters

automatic bobbin change winder fdy yarn bobbin winder machine





       Certification :







Our advantage



1. Have skilled worker available come to support customer for this project , stay at customer,s factory 3-6 months .

2. Have our own yarn production factory , the customer can come and learn machine orperate at our yarn factory

3. Have two kind of drawing system for customer select , godet type and air oven type ,

4. Export to Russia ,Ukrine,European ,India etc , we have professional team including engineer ,worker and sales for 24hr service.

5. Convinient for testing running before delivery .



Aftersales work :

Come engineer help set up machine ,take 10 days for assemble and trainning . 3-4 days for set up,5-6 days for training .

The customer should prepare 3-5 workers for learn and operate the machne .

With online device ,our team is 24hr at your service .







Finished yarn products :



 On the exibition :
