Прямая продажа T8014-Z1BQ-H + u 5A SP on-off on
- Категории: Toggle Switches >>>
- Поставщик: Dongguan,Hongju,Electronic,Hardware,Products,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Specification
item | value |
Certification | REACH, RoHS |
Brand Name | HONGJU |
Max. Current | 5A @125 VAC or 28 VDC |
Max. Voltage | 5A @125 VAC or 28 VDC |
Mechanical Life | 10000 |
Contacting rating | 5A 125VAC |
Electrical Life | 40,000 make-and-break cycles |
Contact Resistance | 10 m max. initial @2-4 VDC,100 mA |
Insulation Resistance | 1,000 M min |
Dielectric Strength | 1,500 V RMS @ sea level |
Operating temperature | -30 C to +85 C |
