Carton and corrugated box compression tester

model number: DRK123





DRK123 Box Compression Tester  is professionally used to test the compression resistance property of carton box, corrugated box, honeycomb cardboard box and other packaging. And it’s also applicable to container compression test of plastic bucket (edible oil, mineral water), fiber drum, carton, paper, cans; container barrels (IBC barrels).

Product features

1. Computer control; eight-inch color touch-screen control panel, high-speed ARM processor to ensure high automaticity, fast data collection, test automatically and intelligent judgment;


2. Three test methods:compression test; stacking test; press standard test;


3. Screen dynamic displays sample No., sample deformation, real-time pressure and initial pressure;


4. Open structure, double screw, double column, reduction gears drive reduction, good parallelism, good stability, strong rigidity, long service life;


5. Serve motor controls with high precise, low noise and high speed advantages; Accurate position and fast response speed save test time;


6. 24 high-precision AD converter (resolution up to 1 / 10,000,000) and high precision weighing sensor to ensure the speed and accuracy of the data acquisition of the instrument force;


7. Ultimate travel protection, overload protection, bugs prompt and fault prompts intelligent configuration to ensure safe operation; Micro-printer can print test data easily.


8. Connecting with computer can display curve, analyze test data, save and print data.



Product application

It is applicable to do compression test, stacking test and press standard test of corrugated carton, cellular board case and so on.

Compressive strength test is applicable to test crushing force of all kinds of corrugated carton, honeycomb plate box and other packaging;

Stacking strength test is applicable to stacking test of all kinds of corrugated carton, honeycomb plate box and other packaging;

Pressure standards compliance test is applicable to pressure standard compliance test of corrugated carton, honeycomb plate box and other packaging;

It is also used to test pressure resistance property of plastic barrels, bottled mineral water bottles, bottled container anti-stress tests



Technical standards

GB/T 4857.4 <Packaging – Transport packages Compression test method>

GB/T 4857.3 <Packaging – Complete, filled transport packages – Stacking tests using static load>

ISO 2872 <Packaging – Complete, filled transport packagings – Compression test>

ISO 2874 <Packaging – Complete, filled transport packagings –Stacking test using compression tester>

QB/T 1048 <Board and carton box – Tester of crush resistance>



Product parameters



















Main fixtures

Mainframe, Control cabinet, Power line, Connecting line, 4 rolls of printer paper

Optional: computer control system
