Экструзионная мини-машина для пластиковой

Описание и отзывы

Характеристики

USAGE
It is the mini type PE plastic film extruder for making PE(HDPE, LDPE, LLDPE) film; etc.
Which kinds of film are widely used for packing liquid, industrial products, garments and textile; for making plastic bags, like T-shirt bag, flat bags, garbage bags etc.

CHARACTERISTIC
1. Mini type machine, structure is very tight, save space and labor force, suitable for small size factory.
2. Main motor and traction motor all adopt frequency inverter controllers.
3. Material of screw and barrel: 38CrMoAlA after nitrogen treatment, supplied from zhoushan city
4. Gear box: hard teeth gear surface gear box
5. Die material: steel alloy.45 material, hard chrome- plating, with two die heads for both LDPE and HDPE.
6. Heating system adopts stainless steel and cast AI heating loops, with double digital display temperature controllers, high precision temperature control.
7. Traction rollers adopt air cylinders open and close, high quality and easy to operate.
8. Rewinder adopts torque motor control, suitable for film rewinding, speed adjustable.
9. Spare parts like air compressor, and air blower are included.



MODEL

Model	SJ-50M	SJ-55M
Raw Material	HDPE, LDPE, LLDPE	HDPE, LDPE, LLDPE
Film blowing width	80-600mm	120-800mm
Film thickness	0.004-0.10mm	0.004-0.10mm
Output	30-40kg/h	40-50kg/h
Power input	380v, 50hz, 3p. 20kw	380v, 50hz, 3p. 25kw
Dimension (l*w*h)	2500*1500*2100mm	2600*1500*2100mm
Weight	1800kg	2000kg
