Concrete Mixer Machine with Concrete Pump Diesel Driven Concrete Mixer

 →Service Hotline/WhatsApp: 008615066732025



--Give us a chance to service for your construction work, you will get greatly support!





Concrete Mixer Machine with Concrete Pump Diesel Driven
Item	unit	parameter
Max. Concrete output	cbm/h	45
Pipe pressure	Mpa	13
Hydraulic system pressure	Mpa	31
Max. horizontal delivery distance	m	280
Max. Vertical height	m	120
Max. Aggregate size	mm	40
Filling height	mm	1400
Valve type	S valve
Main oil pump	KAWASAKI
Lubrication	Automatically
Concrete cylinder bore*stroke	mm	200mm1050
Delivery pipe diameter	mm	125mm
Diesel engine power	kw	85
Wash way	Water washing
Dimension	mm	5500*1750*2650
Weight	kg	5600









Factory Supplier Concrete Mixer Machine with Concrete Pump Diesel

Factory Supplier Concrete Mixer Machine with Concrete Pump Diesel Factory Supplier Concrete Mixer Machine with Concrete Pump Diesel



concrete mixer with concrete pump has been widely used in many construction areas such as Water conservancy, Electricity,Railway, Highway, Tunnel, Mine, National Defense, etc. They have also been exported to many countries and got an excellent reputation . Our products have passed BV and ISO9001 International Quality System Certification and the mining concrete pumps have passed the Safety Certificate of Approval for Mining Products.

1.Power system Concrete Mixer Machine with Concrete Pump

Hydraulic oil pump: Germany Rexroth or Japan Kawasaki are adjusted.

Diesel power: Germany Deutz, Weichai, Yuchai, Cummins .etc.

2.Electronic control system Concrete Mixer Machine with Concrete Pump

Japan Mitsubishi Programmable Logic Controller (PLC) electronic control system. Main electric elements are imported original Schneider, Siemens, OMRON, LG etc.

3.Hydraulic system Concrete Mixer Machine with Concrete Pump

The unique open hydraulic system and hydraulic cushion technology contribute to the smaller exchange impact and less heat of the system. Meanwhile, with the famous brand of main pump and hydraulic valve, the safety and reliability of the concrete pump are guaranteed.

4.Pumping system Concrete Mixer Machine with Concrete Pump Diesel

Pumping displacement variable adjustment: Change the pumping displacement according to the construction to meet the requirement of the condition. Reducing design of the hopper could release the reducing pressure of the concrete into the delivery pipe maximally, and prolong the service life of the S pipe outlet.

5.Lubrication System Concrete Mixer Machine with Concrete Pump

The patented central automatic lubrication system comes with a piston grease-pump, features high pressure and reliability, which can realize automatic lubrication of piston. The filters at the outlet and the inlet of oil ports as double protections guarantee the system reliability.

6.Cooling System Concrete Mixer Machine with Concrete Pump

Compulsory air-cooled heat exchanger keeps the temperature of the hydraulic oil below 60 degree,that ensures the whole hydraulic system works at normal status.

7. Water supply Concrete Mixer Machine with Concrete Pump

Water supply automatically by hydraulic power to the water motor, it is fully powerful water supply for the concrete mixer with pump









Please kindly note:
reinforced package into 40ft container

40ft container can be loaded 2 sets, included 200m delivery pipes
We have professional loading team for this concrete mixer pump, not only loaded it smoothly but also make the most of the contaienr space and save the cost for you



Factory Supplier Concrete Mixer Machine with Concrete Pump Diesel

Factory Supplier Concrete Mixer Machine with Concrete Pump Diesel

Factory Supplier Concrete Mixer Machine with Concrete Pump Diesel

Factory Supplier Concrete Mixer Machine with Concrete Pump Diesel







Concrete Mixer Machine with Concrete Pump Diesel Driven is the multi-function machine designed by our factory, it is combined by the traditional concrete pump and the mixer together, it is the most suitable for use in four to six floor buildings,especially in the group buildings, bridges, and the spread of small construction sits where need theconcrete mixer at the scene.



Concrete Mixer Machine with Concrete Pump , simple to operate, easy to move, flexible, and stable performance. The pump construction operation system used in all automated, all material mixing, high pressure pumping as one; Double cylinder hydraulic pumping system, hydraulic system greatly enhance the the stirring Concrete pump overall reliability ensure pump strive foolproof work under harsh conditions.

Taian Minle Machine Manufacture Co., Ltd is located in Taian City, Shandong Province, China,  We have more 150 employees and with our own professional manufacturing factory for the Concrete Mixer Machine with Concrete Pump





In 1999, we developed the first small diesel concrete pump for the government project, which started our concrete pump business and broke the monopoly of the brand concrete mixer with pump in the Chinese market. our concrete mixer pump serving the construction industry for more than 20 years.





Ten years ago, our concrete machine cement pump with mixer be sold all over the world!  Our concrete machine cement pump with mixer exported to over 36 countries. Our main customers are from Saudi Arabia,Vietnam, Malaysia, Poland, Hong Kong, Malaysia, Hungary, Mexico, Ecuador, Brazil, Pakistan,Thailand, Qatar, Bangladesh,Indonesia, Ethiopia, Somalia, Nigeria, Singapore, Philippines, Sri Lanka, India, Madagascar, UAE, Saudi Arabia, Kenya, Ghana, South Africa, Swaziland, Mongolia, etc.



--Give us a chance to service for your construction work, you will get greatly support!





FAQ:

Q1: Are you trading company or manufacturer?

A: We are factory. We can design and manufacture products with our patent.

Q2: How about your delivery time?

A: Usually 7-10 days if the goods are in stock. or 15-20 days if the goods are not available in stock, it is up to your quantity.

Q3: What is your payment method?

A: 30% of total price should be paid by T/T as down payment; 70% balance payment should be paid by T/T before delivery. We also support L/C, Western Union.Money Gram;

Q4: How many types Concrete Mixer and Pump you have?

A: Diesel driven or electric motor
If you need electric motor one, please let us know your power situation, such as in China, it is 380Voltege & 50 HZ.
If you need diesel motor concrete mixer pump, the brand of diesel engine you like, it is Cummins or Deutz or Chinese Weichai,yuchai?

Q5: What is the capacity of your concrete mixer pump?

A: We have 30m-40m3/h.

Q6: How long and high you want to pump?

A: We can provide 2 floors to 50 floors. Please let us know the vertical and horizontal delivery distance should reach. Or please let me know the tall building's total height.

Q7: The aggregate size that you usually use?

A: 40mm.





-------------------------
