Испытательная машина для истирания Deval Electronic 48-D5242 C-tech

DEVAL ABRASION TESTING MACHINE/MICRO-DEVAL TESTER(APPARATUS)

STANDARD:  EN 1097-1, EN 13450, NF P18-576

This machine is used to determine the resistance to wear of aggregates. The machine consists of a steel frame suitable to house four 200 mm dia.x 154 mm length cylinders (EN 1097-1) or two 200 mm dia.x 400 mm length cylinders (EN 13450). The top machine is enclosed in a sound proof and safety cabinet conforming to CE requirement and stops automatically when the cover is open. The machine is equipped with an automatic counter, which can be preset  to the required number of revolutions of the drum or  the total working time. The four standard cylinders 200 mm dia.x 154 mm length are included. The 400 mm long cylinders and steel spheres are not included and have to be ordered separately. See accessories.

Features:

• Complete with four Stainless steel cylinders      200 mm dia.x154 mm length

• Suitable for rolling two 200 mm dia.x400 mm long cylinders

• Revolutions setting counter included

• Enclosed in safety protection

Main technical parameter:

Accessories EN 1097-1 (need to be ordered separately)

48-D0524/7  Stainless steel spheres 10 mm dia. Pack of 20 kg

Accessories EN 13450 (need to be ordered separately)

48-D524/8  Stainless steel cylinders 200 mm dia. x 400 mm length. Note: Abrasive charge (steel spheres) not required. Accessories  NF P 18-576 (need to be ordered separately)

48-D0524/1  Steel spheres  30 mm dia. Pack of 10.

48-D0524/2  Steel spheres 18 mm dia. Pack of 50.

Spare parts: 48-D0524/4 Four standard Stainless steel cylinders 200mm dia. x 154 mm length

 Packing with wooden pallet.

Shipping by air or sea.

 After-sale service is available.
