DN32 Electric Heating Element Immersion 220V/380V Heater 304 Stainless Steel 1 1/4" Boiler Water Heater



The 5 sizes we show are in stock, which can be sent out in 2days.  Other specificaction can customized. Contact with us freely.

Tube Length	Tube Diameter	Thread Size	Voltage	Power	Material
190mm	8mm	DN32 (1 1/4")	220V/380V	3KW	304SUS
210mm	8mm	DN32 (1 1/4")	220V/380V	4.5KW	304SUS
250mm	8mm	DN32 (1 1/4")	220V/380V	6KW	304SUS
290mm	8mm	DN32 (1 1/4")	220V/380V	9KW	304SUS
355mm	8mm	DN32 (1 1/4")	220V/380V	12KW	304SUS



Heat intensity	Not exceeding 30w/cm2 (advisable)
Exhaust extreme (when cold)	<=0.1mA to 242 v.
Insulation (when cold)	5 Min Ohms 500 Watts minimum
Power	Depends on the dimension
Dielectric strength	1500v. 1/sec
Working temperature	650 Deg C max.
Length tolerance	+/-1.5%
Diameter tolerance	-0.02 to -0.06 mm
Cut off connection tolerance	+/-15 mm
Power tolerance (w)	+5 % - 10 %
Cold areas	Depends on length and diameter 5-25mm
