JHSTC30 Роботизированная ручка для распыления бетона/машина дробовиков влажной дробовки в

JHSTC30

Item

Unit

Parameter

Whole machine

Dimension

mm

9956*2500*3268

Weight

Kg

16200

Working driving mode

-

Electromotor + Diesel

Chssis diesel power

Kw

132

Spraying boom

Turntable rotation angle

°

0 ~ +360

Big arm pitching angle

°

0 ~ +70

Small arm pitching angle relative with big arm

°

-110 ~ +20

Spraying vertical height

m

16

Spraying horizontal distance

m

13

Max,spraying depth

m

5

Spraying head rotation angel

°

360

Spraying head vertical axial swing angle

°

240

Pumping system

Rated output capacity

m³/h

30

Max.output pressure

Mpa

7.5

Reversing times

time

24

System pressure

Mpa

24

Concrete cylinder inner dia.

mm

180

Main oil cylinder inner dia/Rod dia

mm

Φ100/Φ70

Concrete cylinder stroke

mm

1000

Delivery pipe size

mm

Φ100-Φ80

Distribution valve type

-

S Tube valve

Driving system

Alex base

mm

5250

Front and rear axle driving mode

-

Rear wheel drive,front wheel steering

Max. speed

Km/h

90

Grade ability

-

40%

Ground clearance

mm

260

Min.turning radius

m

8.5

Braking length

m

≤8

Hydraulic system

Motor model

-

Y2-315L-4(380)

Three phase asynchronous motor

Rated motor power

Kw

75

Rated voltage/frequency

-

380v-50hz

Rated speed

R/min

1480

Model

-

Full hydraulic reversing open hydraulic system

Oil pump assembly

-

A11VLO130+A11VO60+A10VO28

Pumping oil pressure

Mpa

31.5

Hydraulic tank capacity

L

510

Oil cylinder capacity

L

300

Auxiliary system

Cable speci,length

-

Φ50*3+Φ16*1*50

Additive output flow

L/h

0~1000

Additive output pressure

Mpa

1.8

Accelerator tank capacity

L

1000
